FUEL TANK 3
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
COVER, SIDE 1 (YAMAHA BLACK) (PASTEL DARK GRAY) *{PGD/YB FOR PGD}*
$206.04¢103 019
#2
NUT, SPRING
$1.25¢625
#3
Grommet
$5.72¢2 863
#4
SCREW, TAPPING
$2.26¢1 131
#5
Clamp
$3.81¢1 906
#6
DAMPER, PLATE
$0.69¢344
#7
EMBLEM (replaces 1RC-2413B-00-00)
$23.89¢11 944
#8
GRILL, AIR INTAKE 1
$48.31¢24 156
#9
SCREW, TAPPING
$2.26¢1 131
#10
Grommet
$5.72¢2 863
#11
DUCT 1
$39.86¢19 931
#12
SCREW, TAPPING
$2.26¢1 131
#13
NUT, SPRING
$1.25¢625
#14
RIVET
$6.45¢3 225
#15
MOLE 1
$47.53¢23 763
#16
RIVET
$6.45¢3 225
#17
NUT, SPRING
$1.25¢625
#18
COVER 1
$12.35¢6 175
#19
RIVET
$6.45¢3 225
#20
NUT, SPRING
$1.25¢625
#21
COLLAR
$6.26¢3 131
#22
BOLT,HEX. SOCKET BUTTON
$7.57¢3 787
#23
BOLT
$2.75¢1 375
#24
COVER, SIDE 2 (YAMAHA BLACK) (PASTEL DARK GRAY) *{PGD/YB FOR PGD}*
$169.31¢84 656
#25
NUT, SPRING
$1.25¢625
#26
Grommet
$5.72¢2 863
#27
SCREW, TAPPING
$2.26¢1 131
#28
Clamp
$3.81¢1 906
#29
DAMPER, PLATE
$0.69¢344
#30
EMBLEM (replaces 1RC-2413B-00-00)
$23.89¢11 944
#31
GRILL, AIR INTAKE 2
$48.31¢24 156
#32
SCREW, TAPPING
$2.26¢1 131
#33
Grommet
$5.72¢2 863
#34
DUCT 2
$47.54¢23 769
#35
SCREW, TAPPING
$2.26¢1 131
#36
NUT, SPRING
$1.25¢625
#37
RIVET
$6.45¢3 225
#38
MOLE 2
$47.53¢23 763
#39
RIVET
$6.45¢3 225
#40
NUT, SPRING
$1.25¢625
#41
COVER 2
$12.35¢6 175
#42
RIVET
$6.45¢3 225
#43
NUT, SPRING
$1.25¢625
#44
COLLAR
$6.26¢3 131
#45
BOLT,HEX. SOCKET BUTTON
$7.57¢3 787
#46
BOLT
$2.75¢1 375
#47
COVER, TANK
$22.09¢11 044
#48
RIVET
$6.45¢3 225
#49
DAMPER, PLATE
$1.47¢737
#50
LABEL, WARNING GENERAL INFO.
$3.70¢1 850
#51
GRAPHIC 7
$77.24¢38 619
#52
GRAPHIC 8
$66.19¢33 094
#53
Protector
$1.75¢875
#54
Protector
$1.75¢875
