FUEL TANK 2
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
COVER, SIDE 1 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$145.80¢72 900
#2
COLLAR
$5.99¢2 994
#3
SCREW, BIND
$1.46¢731
#4
NUT, SPRING
$2.82¢1 412
#5
PLUG
$6.76¢3 381
#6
BOLT, HEXAGON SOCKET HEAD
$6.35¢3 175
#7
SCREW, TAPPING
$3.85¢1 925
#8
Damper
$1.95¢975
#9
DAMPER, LOCATING 4
$1.34¢669
#10
MOLE 1
$25.91¢12 956
#11
NUT, SPRING
$1.25¢625
#12
SCOOP, AIR 1 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$175.11¢87 556
#13
BOLT, HEXAGON SOCKET BUTTON
$2.97¢1 487
#14
WASHER, PLATE
$7.66¢3 831
#15
EMBLEM (replaces 1RC-2413B-00-00)
$23.89¢11 944
#16
STAY, SIDE COVER 1 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$105.26¢52 631
#17
NUT, SPRING
$1.25¢625
#18
NUT, SPRING
$2.82¢1 412
#19
GROMMET
$7.43¢3 713
#20
COLLAR
$7.43¢3 713
#21
BOLT, FLANGE
$2.15¢1 075
#22
CAP 1 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$54.13¢27 063
#23
NUT, SPRING
$0.50¢250
#24
GRILL, AIR INTAKE 1
$37.86¢18 931
#25
RIVET
$8.34¢4 169
#26
COVER, SIDE 2 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$145.80¢72 900
#27
COLLAR
$5.99¢2 994
#28
SCREW, BIND
$1.46¢731
#29
NUT, SPRING
$2.82¢1 412
#30
PLUG
$6.76¢3 381
#31
BOLT, HEXAGON SOCKET HEAD
$6.35¢3 175
#32
SCREW, TAPPING
$3.85¢1 925
#33
Damper
$1.95¢975
#34
DAMPER, LOCATING 4
$1.34¢669
#35
MOLE 2
$27.56¢13 781
#36
NUT, SPRING
$1.25¢625
#37
SCOOP, AIR 2 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$175.11¢87 556
#38
BOLT, HEXAGON SOCKET BUTTON
$2.97¢1 487
#39
WASHER, PLATE
$7.66¢3 831
#40
EMBLEM (replaces 1RC-2413B-00-00)
$23.89¢11 944
#41
STAY, SIDE COVER 2 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$99.60¢49 800
#42
NUT, SPRING
$7.26¢3 631
#43
NUT, SPRING
$1.25¢625
#44
NUT, SPRING
$2.82¢1 412
#45
CAP 2 (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$52.16¢26 081
#46
NUT, SPRING
$0.50¢250
#47
GRILL, AIR INTAKE 1
$37.86¢18 931
#48
RIVET
$8.34¢4 169
#49
COVER, TANK (DARK BLUISH GRAY METALLIC 8) *{DBNM8}*
$60.38¢30 188
#50
RIVET
$3.46¢1 731
#51
Damper
$7.86¢3 931
#52
GUIDE, AIR 1
$15.74¢7 869
#53
GRILL, AIR OUTLET 1
$39.89¢19 944
#54
NUT, SPRING
$0.50¢250
#55
GUIDE, AIR 2
$14.26¢7 131
#56
GRILL, AIR OUTLET 2
$42.42¢21 213
#57
NUT, SPRING
$0.50¢250
#58
BRACKET 1
$32.24¢16 119
#59
NUT, SPRING
$7.26¢3 631
#60
CAP, GREASE NIPPLE
$2.23¢1 113
#61
NUT, FLANGE
$2.44¢1 219
#62
BOLT, FLANGE DEEP RECESS
$0.47¢238
#63
GROMMET
$3.49¢1 744
#64
BRACKET 2
$31.81¢15 906
#65
GROMMET
$7.43¢3 713
#66
COLLAR
$7.43¢3 713
#67
BOLT, FLANGE
$2.15¢1 075
#68
PLUG
$6.76¢3 381
#69
BOLT, FLANGE DEEP RECESS
$0.47¢238
#70
BRACKET, SEAT
$8.81¢4 406
#71
SCREW, TAPPING
$3.85¢1 925
#72
GRAPHIC 1
$44.77¢22 388
#73
GRAPHIC 2
$44.77¢22 388
