RADIATOR HOSE

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de RADIATOR HOSE

Repuestos

#1
5SL-12410-00-00
THERMOSTAT ASSY
$54.82¢27 410
1
#2
2C0-12413-00-00
COVER, THERMOSTAT
$26.88¢13 438
1
#3
91314-06020-00
BOLT (3JB) (replaces 91312-06020-00)
$2.24¢1 121
1
#4
2C0-12578-00-00
HOSE 3
$4.28¢2 139
1
#5
2C0-12481-00-00
PIPE 1
$54.81¢27 404
1
#6
90450-35001-00
HOSE CLAMP ASSY
$5.76¢2 881
1
#7
2C0-12552-00-00
HOSE 8
$38.51¢19 257
1
#8
90450-35001-00
HOSE CLAMP ASSY
$5.76¢2 881
1
#9
5GV-1246E-00-00
COVER 2
$4.42¢2 208
1
#10
13S-12461-00-00
RADIATOR COMP
$601.22¢300 610
1
#11
2C0-12405-00-00
BLOWER ASSY
$529.09¢264 546
1
#12
2C0-12405-10-00
BLOWER ASSY
$529.09¢264 546
1
#13
5GJ-12675-00-00
BOLT, BLOWER HOLDING
$7.30¢3 651
1
#14
2C0-12659-00-00
DAMPER, AIR SHROUD 2
$7.28¢3 640
1
#15
2C0-12668-00-00
DAMPER, AIR SHROUD 3
$7.23¢3 617
1
#16
90480-15363-00
GROMMET
$6.75¢3 375
1
#17
90387-07391-00
COLLAR
$8.49¢4 244
1
#18
90387-0614M-00
COLLAR
$9.04¢4 520
1
#19
90480-11005-00
GROMMET
$6.03¢3 013
1
#20
13S-12659-00-00
DAMPER, AIR SHROUD 2
$7.23¢3 617
1
#21
13S-12678-00-00
DAMPER, AIR SHROUD 5
$7.23¢3 617
1
#22
13S-12688-00-00
DAMPER, SHROUD 7
$7.23¢3 617
1
#23
5SL-12462-00-00
CAP, RADIATOR
$34.52¢17 261
1
#24
90105-06040-00
BOLT, FLANGE
$6.24¢3 122
1
#25
95817-06035-00
BOLT, FLANGE
$5.89¢2 944
1
#26
91317-06035-00
BOLT
$3.84¢1 920
1
#27
90387-0614M-00
COLLAR
$9.04¢4 520
1
#28
90201-063J2-00
WASHER, PLATE
$4.88¢2 438
1
#29
2C0-12535-00-00
PLATE
$17.09¢8 545
1
#30
13S-12669-00-00
DAMPER, AIR SHROUD 4
$7.23¢3 617
1
#31
90269-07007-00
RIVET
$3.68¢1 840
1
#32
2C0-1244E-00-00
BRACKET 1
$12.56¢6 279
1
#33
95817-06012-00
BOLT, FLANGE (replaces 95827-06012-00)
$1.64¢822
1
#34
2C0-12579-00-00
HOSE 4
$43.49¢21 746
1
#35
90450-35001-00
HOSE CLAMP ASSY
$5.76¢2 881
1
#36
2C0-12582-00-00
JOINT, HOSE 2
$61.77¢30 883
1
#37
2C0-12551-00-00
HOSE 7
$22.61¢11 305
1
#38
90450-35001-00
HOSE CLAMP ASSY
$5.76¢2 881
1
#39
90467-10M04-00
CLIP
$6.70¢3 352
1
#39
90450-35001-00
HOSE CLAMP ASSY
$5.76¢2 881
1
#40
90467-310A0-00
CLIP
$4.61¢2 306
1
#41
2C0-12589-00-00
HOSE 6
$26.69¢13 346
1
#42
90467-200A0-00
CLIP
$8.69¢4 347
1
#43
90450-22M14-00
HOSE CLAMP ASSY
$15.11¢7 555
1
#44
2C0-12491-00-00
CLAMP 1
$17.31¢8 654
1
#45
95027-10020-00
BOLT, FLANGE
$2.77¢1 386
1
#46
2C0-21871-00-00
TANK, RECOVERY
$55.67¢27 836
1
#47
90387-06681-00
COLLAR
$7.24¢3 622
1
#48
2C0-21875-00-00
CAP
$15.65¢7 826
1
#49
26H-21828-00-00
ELBOW
$24.05¢12 023
1
#50
2C0-21816-00-00
PIPE 1
$12.14¢6 072
1
#51
2C0-1243F-00-00
HOSE,3
$7.53¢3 766
1
#52
90467-08003-00
CLIP
$6.90¢3 450
1
#54
90467-08003-00
CLIP
$6.90¢3 450
1
#55
95817-06014-00
BOLT, FLANGE (replaces 95802-06014-00)
$2.44¢1 219
1
#56
90464-10M38-00
CLAMP
$8.49¢4 244
1
#57
13S-2836H-00-00
BRACKET 5
$29.91¢14 956
1
#58
90183-06069-00
NUT, SPRING
$6.68¢3 341
1
#59
95817-06014-00
BOLT, FLANGE (replaces 95802-06014-00)
$2.44¢1 219
1
#60
2C0-1246H-00-00
COVER 5
$10.74¢5 371
1
#61
13S-12668-00-00
DAMPER, AIR SHROUD 3
No Disponible
1
#62
90269-06001-00
RIVET
$5.93¢2 967
1
