GOVERNOR

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de GOVERNOR

Repuestos

#1
4JY-11915-10-00
PLATE, THRUST 1
$7.65¢3 825
1
#2
98904-05012-00
SCREW,BINDING
$1.46¢731
1
#3
90105-05014-00
BOLT, FLANGE
$2.64¢1 319
1
#4
90201-05021-00
WASHER, plate
$1.96¢981
1
#5
90387-085E1-00
COLLAR
$6.40¢3 200
1
#6
93104-08040-00
OIL SEAL
$14.56¢7 281
1
#7
5CU-11990-10-00
PUSH ROD ASSY
$138.31¢69 156
1
#8
3JE-11922-01-00
FORK, GOVERNOR
$45.05¢22 525
1
#9
91312-04006-00
BOLT
$3.23¢1 613
1
#10
93300-60801-00
BEARING
$24.89¢12 444
1
#11
93300-60801-00
BEARING
$24.89¢12 444
1
#12
5X4-11921-02-00
SHAFT, GOVERNOR
$61.40¢30 700
1
#13
5NY-11953-00-00
GEAR, GOVERNOR
$64.40¢32 200
1
#14
90501-290A2-00
SPRING, COMPRESSION
$18.34¢9 169
1
#15
5CU-11952-00-00
PLATE
$18.65¢9 325
1
#16
90201-150U6-00
WASHER, PLATE
$9.46¢4 731
1
#17
90387-152F2-00
COLLAR
$13.38¢6 688
1
#18
93340-21505-00
BEARING
$19.85¢9 925
1
#19
5CU-11912-00-00
RETAINER, WEIGHT
$68.24¢34 119
1
#20
5CU-11911-00-00
RETAINER
$138.85¢69 425
1
#21
93507-16020-00
BALL
$2.11¢1 056
1
#22
93603-14240-00
PIN, DOWEL
$1.86¢931
1
#23
93604-29184-00
PIN, DOWEL | AP
$2.71¢1 356
1
