TAILLIGHT

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de TAILLIGHT

Repuestos

#1
2CR-84710-00-00
TAILLIGHT UNIT ASSY
$190.07¢95 036
1
#2
90269-06008-00
RIVET
$8.10¢4 048
1
#3
BN6-21615-00-00
WASHER, SPECIAL 1
$6.07¢3 036
1
#4
91314-06025-00
BOLT, HEXAGON SOCKET HEAD
$7.30¢3 651
1
#5
2C0-21629-11-00
GUARD, MUD
$34.78¢17 388
1
#6
5VX-84745-01-00
LICENSE LIGHT UNIT ASSY
$95.47¢47 736
1
#7
4SV-84347-00-00
BULB (12V-5W)
$7.04¢3 519
1
#8
97707-40012-00
SCREW, TAPPING
$7.31¢3 657
1
#9
90183-05061-00
NUT, SPRING
$4.35¢2 173
1
#10
98902-05014-00
SCREW, BIND
$1.32¢661
1
#11
3Y6-85130-02-00
Rear Reflector
$24.91¢12 455
1
#12
95607-05200-00
NUT,U FLANGE (replaces 95602-05200-00)
$7.51¢3 755
1
#13
BN6-21640-00-00
REAR STAY COMP.
$262.07¢131 037
1
#14
BN6-2163E-00-00
COVER, REAR FENDER 2
$26.35¢13 173
1
#15
90464-14228-00
CLAMP
$4.86¢2 432
1
#16
90109-06182-00
BOLT
$12.62¢6 308
1
#17
5VX-13569-01-00
PLUG, BLIND
$7.31¢3 657
1
#18
3Y6-85130-02-00
Rear Reflector
$24.91¢12 455
1
#19
95702-05500-00
NUT,FLANGE (SILVER)
$0.84¢420
1
#20
2C0-21688-00-00
BRACKET, REAR STAY
$11.81¢5 905
1
#21
2C0-21689-00-00
BRACKET, REAR STAY 2
$11.53¢5 767
1
#22
90159-06011-00
SCREW, WITH WASHER
$6.80¢3 398
1
#23
95617-06100-00
NUT,U (replaces 95602-06100-00)
$2.63¢1 317
1
#24
5MT-84751-00-00
BRACKET, LICENSE
$26.96¢13 478
1
#25
90201-06057-00
WASHER, PLATE
$4.13¢2 064
1
#26
95617-06100-00
NUT,U (replaces 95602-06100-00)
$2.63¢1 317
1
