REAR FENDER
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
BOX, BATTERY 1
$99.00¢49 502
#2
DAMPER
$7.23¢3 617
#3
PLATE 1
$5.99¢2 996
#4
NUT, SPRING
$6.68¢3 341
#5
BOLT
$2.98¢1 489
#6
RIVET
$2.78¢1 392
#7
BAND, BATTERY
$23.89¢11 943
#8
BOLT, FLANGE
$3.29¢1 644
#9
NUT, SPRING
$1.15¢575
#10
BOX
$10.68¢5 342
#11
RIVET
$8.10¢4 048
#12
BRACKET, TAILLIGHT
$71.71¢35 857
#13
BOLT, HEXAGON SOCKET HEAD
$8.92¢4 462
#14
DAMPER
$3.68¢1 840
#15
ROTOR SET
$77.72¢38 859
#16
BOLT, FLANGE
$2.89¢1 443
#17
SEAT LOCK ASSY
$28.65¢14 323
#18
NUT, FLANGE
$2.24¢1 121
#19
BRACKET, SEAT LOCK
$5.78¢2 892
#20
BOLT, HEX. SOCKET BUTTON
$4.28¢2 139
#21
NUT, SPRING
$2.60¢1 299
#22
NUT, SPRING
$1.15¢575
#23
GUARD, MUD
$63.28¢31 642
#24
BOLT
$4.38¢2 191
#25
Collar
$6.65¢3 323
#26
WASHER, PLATE
$4.13¢2 064
#27
NUT,SELF-LOCKING
$7.98¢3 991
#28
Rear Reflector
$24.91¢12 455
#29
NUT,U FLANGE (replaces 95602-05200-00)
$7.51¢3 755
#30
LICENSE LIGHT UNIT ASSY
$264.97¢132 486
#31
Collar
$7.28¢3 640
#32
GROMMET
$0.89¢443
#33
WEIGHT
$7.14¢3 571
#34
Bracket
$146.66¢73 330
#35
REFLECTOR, REAR 1
$28.22¢14 110
#36
NUT, FLANGE
$6.76¢3 381
#37
WASHER, PLATE
$4.13¢2 064
#38
NUT-U (replaces 95602-06200-00)
$2.58¢1 288
#39
PLUG
$4.43¢2 214
#40
STAY, FENDER 1
$103.13¢51 566
#41
STAY, FENDER 2
$103.17¢51 583
#42
BRACKET 3
$14.48¢7 239
#43
BOLT, FLANGE (replaces 95802-06014-00)
$2.44¢1 219
#44
CLAMP
$2.90¢1 449
#45
WIRE, SUB-LEAD
$26.45¢13 225
#46
BOLT, HEXAGON
$6.16¢3 082
#47
COVER, REAR FENDER
$60.06¢30 032
#48
SCREW, TRUSS HEAD TAPPING
$3.54¢1 771
#49
CAP, ROTOR
$4.30¢2 151
#50
PIN
$4.94¢2 472
#51
SPRING, TORSION
$2.05¢1 023
#52
CIRCLIP
$7.31¢3 657
#53
LABEL, CAUTION
No Disponible
#54
LABEL, CAUTION
$4.54¢2 271
#55
DAMPER, SEAT
$4.86¢2 432
