CRANKCASE COVER 1

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de CRANKCASE COVER 1

Repuestos

#1
B7N-15411-00-00
COVER, CRANKCASE 1
$133.34¢66 669
1
#2
90340-36008-00
PLUG, STRAIGHT SCREW
$21.02¢10 513
1
#3
93210-357A3-00
O-RING
$0.59¢294
1
#4
92017-08012-00
BOLT, BUTTON HEAD
$7.35¢3 675
1
#5
90430-08143-00
GASKET
$3.67¢1 838
1
#6
BD5-15451-00-00
GASKET, CRANKCASE CO (replaces 1RC-15451-00-00)
$19.55¢9 775
1
#7
1RC-12564-00-00
PIPE, WATER
$7.08¢3 538
1
#8
93210-28543-00
O-RING
$3.38¢1 688
1
#9
99530-08012-00
PIN, DOWEL
$6.25¢3 125
1
#10
90110-06388-00
BOLT, HEXAGON SOCKET HEAD
$5.84¢2 919
1
#11
90110-06389-00
BOLT, HEXAGON SOCKET HEAD
$5.84¢2 919
1
#12
90110-06394-00
BOLT, HEXAGON SOCKET HEAD
$2.11¢1 056
1
#13
1RC-15484-00-00
CLAMP 2
$5.51¢2 756
1
#14
90110-06168-00
BOLT, HEXAGON SOCKET HEAD
$5.65¢2 825
1
#15
B7N-15199-00-00
BRACKET
$8.97¢4 488
1
#16
B7N-14867-00-00
BRACKET
$5.17¢2 588
1
#17
B7N-14868-00-00
BRACKET 2
$8.69¢4 344
1
#18
B7N-14869-00-00
BRACKET 3
$6.91¢3 456
1
#19
B7N-15421-00-00
COVER, CRANKCASE 2
$152.54¢76 269
1
#20
93610-20189-00
PIN, DOWEL
$4.13¢2 063
1
#21
90110-06388-00
BOLT, HEXAGON SOCKET HEAD
$5.84¢2 919
1
#22
90110-06321-00
BOLT, HEXAGON SOCKET HEAD
$3.25¢1 625
1
#23
B7N-15499-00-00
PROTECTOR, COVER
$34.69¢17 344
1
#24
B7N-15789-00-00
DAMPER
$5.46¢2 731
1
#25
5GJ-15363-10-00
PLUG, OIL
$21.74¢10 869
1
#26
93210-19123-00
O-Ring
$8.24¢4 119
1
#27
B7N-15416-00-00
COVER, OIL PUMP
$65.06¢32 531
1
#28
B7N-15456-00-00
GASKET, OIL PUMP COVER 1
$12.35¢6 175
1
#29
90110-06396-00
BOLT, HEXAGON SOCKET HEAD
$2.97¢1 487
1
#30
90465-06M90-00
CLAMP
$4.35¢2 175
1
