GOVERNOR

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de GOVERNOR

Repuestos

#1
4JY-11915-10-00
PLATE, THRUST 1
$7.04¢3 519
1
#2
98517-05012-00
SCREW, PAN HEAD
$4.28¢2 139
1
#3
1C3-11990-10-00
PUSH ROD ASSY
$186.50¢93 248
1
#4
90387-085E1-00
COLLAR
$5.89¢2 944
1
#5
90201-05021-00
WASHER, plate
$1.81¢903
1
#6
97017-05012-00
BOLT
$6.75¢3 375
1
#7
93104-08040-00
OIL SEAL
$13.40¢6 699
1
#8
3JE-11922-01-00
FORK, GOVERNOR
$41.45¢20 723
1
#9
91312-04006-00
BOLT
$2.97¢1 483
1
#10
93300-60814-00
BEARING (1LX) (replaces 93300-60801-00)
$22.90¢11 448
1
#11
5X4-11921-02-00
SHAFT, GOVERNOR
$56.49¢28 244
1
#12
5NY-11953-00-00
GEAR, GOVERNOR
$59.25¢29 624
1
#13
90501-320A1-00
Spring, Compression
$16.54¢8 269
1
#14
5CU-11952-00-00
PLATE
$17.16¢8 579
1
#15
90201-150U6-00
WASHER, PLATE
$8.71¢4 353
1
#16
90387-152F2-00
COLLAR
$12.30¢6 152
1
#17
93340-21505-00
BEARING
$18.26¢9 131
1
#18
5CU-11912-00-00
RETAINER, WEIGHT
$62.78¢31 389
1
#19
5CU-11911-00-00
RETAINER
$127.74¢63 871
1
#20
93507-16020-00
BALL
$1.94¢972
1
#21
93603-14240-00
PIN, DOWEL
$1.71¢857
1
#22
90387-103U7-00
COLLAR | AP
No Disponible
1
