MIDDLE DRIVE GEAR

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de MIDDLE DRIVE GEAR

Repuestos

#1
2DF-17541-00-00
CASE, TRANSFER 1
$322.23¢161 115
1
#2
2DF-15417-00-00
COVER, CAP
$180.29¢90 143
1
#3
2DF-15457-00-00
Gasket
$35.85¢17 923
1
#4
99530-10116-00
PIN, DOWEL
$3.68¢1 840
1
#5
90110-06403-00
BOLT, HEXAGON SOCKET HEAD
$2.33¢1 167
1
#6
2DF-176B0-00-00
REDUCTION GEAR ASSY 1
$231.83¢115 914
1
#7
93306-30101-00
BEARING
$35.58¢17 790
1
#8
93306-30002-00
BEARING
$41.14¢20 568
1
#9
2DF-176C0-00-00
REDUCTION GEAR ASSY. 2
$156.24¢78 120
1
#10
93306-00013-00
BEARING(JN9)
$35.56¢17 779
1
#11
93306-90004-00
BEARING(JN9)
$37.92¢18 958
1
#12
2DF-1761A-00-00
SHAFT 1
$16.38¢8 188
1
#13
2DF-17841-00-00
Gear, Driven
$135.54¢67 770
1
#14
2DF-17622-00-00
Boss
$90.04¢45 022
1
#15
2DF-17655-00-00
DAMPER, SLIDER
$16.41¢8 205
1
#16
2DF-16118-00-00
PLATE, SIDE 1
$8.07¢4 036
1
#17
90149-04003-00
Screw
$1.55¢776
1
#18
2DF-17285-00-00
CLUTCH, DOG
$102.80¢51 399
1
#19
2DF-17143-00-00
GEAR, REVERSE PINION 1
$91.79¢45 896
1
#20
93310-41783-00
BEARING
$22.84¢11 420
1
#21
90201-17257-00
WASHER, PLATE
$7.27¢3 634
1
#22
2DF-1761E-00-00
Shaft 2
$13.13¢6 567
1
#23
2DF-1760E-00-00
GEAR 2
$35.37¢17 687
1
#24
93310-41760-00
BEARING
$10.29¢5 146
1
#25
90201-17257-00
WASHER, PLATE
$7.27¢3 634
1
#26
2DF-17243-00-00
GEAR, REVERSE WHEEL 1
$156.70¢78 349
1
#27
2DF-18155-00-00
SHAFT, SHIFT 2
$109.80¢54 901
1
#28
2DF-18311-00-00
FORK, SHIFT 1
$89.68¢44 838
1
#29
93605-20004-00
Pin, Dowel
$0.55¢276
1
#30
90501-121A3-00
Spring, Compression
$2.44¢1 219
1
#31
2DF-17644-00-00
SEAT,SPRING
$14.48¢7 239
1
#32
93440-16148-00
CIRCLIP
$0.62¢311
1
#33
93306-90201-00
BEARING
$23.24¢11 621
1
#34
93306-90001-00
BEARING
$59.68¢29 842
1
#35
93102-15008-00
Oil Seal
$9.43¢4 715
1
#36
2DF-17929-00-00
GASKET 1
$13.42¢6 710
1
#37
91812-16001-00
PIN, DOWEL
$5.66¢2 829
1
#38
2DF-15481-00-00
BOLT 1
$4.22¢2 110
1
#39
2DF-15482-00-00
BOLT 2
$6.09¢3 048
1
#40
90116-08089-00
BOLT, stud
$4.34¢2 168
1
#41
90179-08045-00
Nut
$0.67¢333
1
#42
90201-08366-00
WASHER, PLATE
$7.65¢3 824
1
#43
95812-06050-00
BOLT, FLANGE
$1.66¢828
1
#44
90105-06220-00
Bolt, Flange
$1.93¢966
1
#45
90119-08171-00
BOLT, WITH WASHER
$3.76¢1 880
1
#46
2DF-15359-00-00
HOUSING, OIL SEAL
$44.26¢22 132
1
#47
93210-74001-00
O-Ring
$14.65¢7 326
1
#48
93450-85173-00
Circlip
$6.20¢3 099
1
#49
2DF-13191-00-00
PIPE, DELIVERY 4
$36.42¢18 210
1
#50
93210-06010-00
O-Ring
$7.53¢3 766
1
#51
90401-08015-00
BOLT, union
$47.83¢23 914
1
#52
90430-08119-00
GASKET
$6.36¢3 180
1
#53
2DF-13411-00-00
STRAINER, OIL
$13.06¢6 532
1
#54
93210-26001-00
O-Ring
$5.45¢2 726
1
#55
2DF-13417-00-00
COVER, STRAINER
$60.28¢30 141
1
#56
95817-06020-00
BOLT, FLANGE (replaces 95802-06020-00)
$3.05¢1 524
1
#57
2DF-85899-00-00
SENSOR, GEAR POSITION
$64.68¢32 338
1
#58
93210-17008-00
O-RING
$1.99¢995
1
#59
90110-05067-00
BOLT, HEXAGON SOCKET HEAD
$6.88¢3 439
1
#60
2DF-17076-00-00
Cover
$17.04¢8 522
1
#61
90110-05073-00
BOLT, HEXAGON SOCKET HEAD
$1.13¢564
1
#62
2DF-83755-01-00
SENSOR, SPEED
$77.07¢38 537
1
#63
90110-06125-00
BOLT, HEXAGON SOCKET HEAD
$1.35¢673
1
