MIDDLE DRIVE GEAR 2
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
ARM, SHIFT 2
$50.59¢25 294
#2
BOLT (4FL)
$2.60¢1 300
#3
Spring, Tension
$4.45¢2 225
#4
BRACKET, SHIFTE
$49.09¢24 544
#5
Hook, Spring
$0.96¢481
#6
BEARING
$47.73¢23 863
#7
OIL SEAL
$9.94¢4 969
#8
SHAFT, RINK
$52.02¢26 013
#9
WASHER, PLATE
$7.34¢3 669
#10
CIRCLIP
$7.48¢3 738
#11
PLATE 1
$16.40¢8 200
#12
BOLT
$8.39¢4 194
#13
PIN, DOWEL
$4.00¢2 000
#14
BOLT, FLANGE
$6.69¢3 344
#15
BOLT, FLANGE
$7.34¢3 669
#16
ROD, SHIFT
$45.95¢22 975
#17
Nut
$3.49¢1 744
#18
NUT(JN5)
$7.95¢3 975
#19
LEVER COMP. 1
$378.26¢189 131
#20
BOLT
$2.79¢1 394
#21
MOTOR ASSY
$1254.85¢627 425
#22
BRUSH SET
$89.60¢44 800
#23
BUSH, TERMINAL
$6.21¢3 106
#24
O-Ring
$7.94¢3 969
#25
WASHER, PLAIN
$5.06¢2 531
#26
WASHER
$1.84¢919
#27
NUT
$7.34¢3 669
#28
GASKET
$14.89¢7 444
#29
SCREW
$6.54¢3 269
#30
O-Ring
$7.13¢3 563
#31
BOLT 2
$4.86¢2 431
#32
CORD COMP.
$80.92¢40 463
#33
NUT
$7.34¢3 669
#34
CLAMP
$1.56¢781
#35
WASHER, PLATE
$0.93¢463
#36
PIN, DOWEL
$6.25¢3 125
#37
BOLT, HEXAGON SOCKET HEAD
$1.84¢919
#38
PLATE, 1
$40.91¢20 456
#39
CIRCLIP
$7.34¢3 669
#40
WASHER,PLATE (replaces 90201-12163-00)
$4.17¢2 088
#41
WASHER, PLATE
$7.48¢3 738
#42
SHAFT, SHIFTER
$17.75¢8 875
#43
NUT(JN5)
$7.95¢3 975
#44
Nut
$3.49¢1 744
#45
Bracket
$31.25¢15 625
#46
WASHER, PLATE
$6.35¢3 175
#47
PLATE, 2
$57.75¢28 875
#48
WASHER, plate
$4.79¢2 394
#49
WASHER, WAVE
$0.41¢206
#50
BOLT This item has been discontinued and may not be available. Contact us for more information.
No Disponible
#51
Shaft 2
$36.95¢18 475
#52
BUSH, SOLID
$1.44¢719
#53
WASHER
$7.35¢3 675
#54
PIN. COTTER
$2.20¢1 100
#55
PLATE, 3
$32.94¢16 469
#56
SHAFT, STOPPER
$49.97¢24 987
#57
CIRCLIP
$7.34¢3 669
#58
WASHER, PLATE
$7.48¢3 738
#59
WASHER, PLAIN
$4.26¢2 131
#60
CIRCLIP
$3.60¢1 800
#61
WASHER, WAVE
$5.25¢2 625
#62
WASHER, PLATE
$2.76¢1 381
