TRAVEL BAG

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de TRAVEL BAG

Repuestos

#1
2DF-2840E-02-P1
TRAVEL TRUNK COMP. (replaces 2DF-2840E-00-P1)
$5276.24¢2 638 119
1
#1
2DF-2840E-02-P0
TRAVEL TRUNK COMP. (replaces 2DF-2840E-00-P0)
$7714.99¢3 857 494
1
#2
2DF-284AL-00-00
SEAL, 8
$18.38¢9 188
1
#3
2DF-2842E-01-P0
TRAVEL TRUNK UPPER (replaces 2DF-2842E-00-P0)
$574.92¢287 463
1
#3
2DF-2842E-01-P1
TRAVEL TRUNK UPPER (replaces 2DF-2842E-00-P1)
$526.02¢263 013
1
#4
2DF-2841V-01-00
COVER, 7 (replaces 2DF-2841V-00-00)
$184.40¢92 200
1
#5
90183-05073-00
Nut, Spring
$12.75¢6 375
1
#6
90154-05004-00
SCREW, BINDING
$3.85¢1 925
1
#7
2DF-2848J-01-00
PLATE, RUBBER 8 (replaces 2DF-2848J-00-00)
$16.95¢8 475
1
#8
2DF-2849J-01-00
PLATE, RUBBER 9 (replaces 2DF-2849J-00-00)
$18.82¢9 413
1
#9
1RC-2413B-01-00
EMBLEM (replaces 1RC-2413B-00-00)
$23.89¢11 944
1
#10
2DF-84790-00-00
HIGH MOUNT STOP LAMP ASSY
$632.40¢316 200
1
#11
2DF-86174-00-00
WIRE, LEAD 4
$14.09¢7 044
1
#12
97702-50016-00
TAPPING SCREW
$2.36¢1 181
1
#13
90201-05033-00
WASHER, PLATE
$8.45¢4 225
1
#14
2DF-2848Y-00-00
COVER, LOCK
$372.21¢186 106
1
#15
90154-05004-00
SCREW, BINDING
$3.85¢1 925
1
#16
2DF-W2847-11-00
TRAVEL TRUNK UPPER SET (replaces 2DF-W2847-10-00)
$283.35¢141 675
1
#17
2DF-28493-00-00
COVER LOCK ASSY 2
$166.08¢83 038
1
#18
90109-05007-00
BOLT
$0.56¢281
1
#19
95702-05500-00
NUT,FLANGE (SILVER)
$0.91¢456
1
#20
90154-05004-00
SCREW, BINDING
$3.85¢1 925
1
#21
90119-06212-00
BOLT, WITH WASHER
$7.41¢3 706
1
#22
2DF-28416-00-00
DAMPER 2
$151.54¢75 769
1
#23
90269-07015-00
RIVET
$1.23¢613
1
#24
90464-16019-00
Clamp
$0.83¢413
1
#25
4XY-28446-02-00
LABEL, CAUTION
$9.64¢4 819
1
