OIL COOLER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de OIL COOLER

Repuestos

#1
5JW-13470-10-00
OIL COOLER ASSY
$688.84¢344 419
1
#2
5JW-13473-00-00
O-Ring
$39.87¢19 935
1
#3
90110-06163-00
BOLT, HEXAGON SOCKET
$8.39¢4 198
1
#4
5GH-13440-50-00
ELEMENT ASSY, OIL CLEANER
$15.49¢7 745
1
#5
90401-20008-00
BOLT, UNION
$21.02¢10 511
1
#6
5PW-13490-00-00
RELIEF VALVE ASSY
$102.05¢51 025
1
#7
93210-15566-00
O-RING
$6.32¢3 162
1
#8
5JW-13417-00-00
COVER, STRAINER
$383.59¢191 797
1
#9
5JW-13414-01-00
GASKET, STRAINER COVER
$42.08¢21 039
1
#10
91317-06025-00
BOLT
$2.24¢1 121
1
#11
90340-14132-00
PLUG, STRAIGHT SCREW
$2.90¢1 449
1
#12
214-11198-01-00
GASKET
$2.97¢1 483
1
#13
90465-10041-00
CLAMP
$2.50¢1 248
1
#14
90465-08277-00
CLAMP
$10.68¢5 342
1
#15
90462-08039-00
CLAMP
$2.77¢1 386
1
#16
1MC-1464L-00-00
BRACKET, 4-1
$23.41¢11 707
1
#17
94581-85078-00
CHAIN
$27.53¢13 766
1
#18
5JW-13898-00-00
HOLDER
$43.80¢21 902
1
#19
91317-06012-00
BOLT
$6.75¢3 375
1
#20
2C0-13416-00-00
PIPE, OIL 1
$58.49¢29 245
1
#21
93210-14003-00
O-RING
$7.07¢3 536
1
#22
91317-06016-00
BOLT
$1.35¢673
1
#23
5JW-13161-00-00
PIPE, DELIVERY 1
$18.60¢9 298
1
#24
91317-06012-00
BOLT
$6.75¢3 375
1
#25
B88-1316E-00-00
PIPE, DELIVERY 5
$49.47¢24 737
1
#26
93210-09350-00
O-RING (replaces 93210-09165-00)
$6.36¢3 180
1
#27
93210-06667-00
O-RING
$6.36¢3 180
1
#28
5JW-13354-00-00
SPROCKET, DRIVE
$85.01¢42 504
1
#29
93315-23607-00
BEARING
$22.59¢11 293
1
