STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#001
28333-300-000
SPRING, KICK STARTER STOPPER
$3.36¢1 679
1
#1
28333-300-000
SPRING, KICK STARTER STOPPER
$3.36¢1 679
1
#002
50600-MFJ-D00
HOLDER, R. MAIN STEP
$132.33¢66 165
1
#2
50600-MFJ-D00
HOLDER, R. MAIN STEP
$132.33¢66 165
1
#003
50603-MFJ-D00
PIN, STEP JOINT
$3.06¢1 529
1
#3
50603-MFJ-D00
PIN, STEP JOINT
$3.06¢1 529
1
#004
50607-MEE-000
GUARD, R. STEP
No Disponible
1
#4
50607-MEE-000
GUARD, R. STEP
No Disponible
1
#004
50607-MEE-010
GUARD, R. STEP
$19.37¢9 683
1
#4
50607-MEE-010
GUARD, R. STEP
$19.37¢9 683
1
#005
50617-MCJ-750
SPRING, R. STEP RETURN
$4.74¢2 369
1
#5
50617-MCJ-750
SPRING, R. STEP RETURN
$4.74¢2 369
1
#6
50644-MCJ-750
SPRING, L. STEP RETURN
$4.74¢2 369
1
#006
50644-MCJ-750
SPRING, L. STEP RETURN
$4.74¢2 369
1
#007
50660-MFJ-D00
ARM, Right MAIN STEP
$64.20¢32 102
1
#7
50660-MFJ-305
ARM, R. MAIN STEP (COO)
$64.20¢32 102
1
#007
50660-MFJ-305
ARM, R. MAIN STEP (COO)
$64.20¢32 102
1
#8
50665-MFJ-305
ARM, L. MAIN STEP (COO)
$64.20¢32 102
1
#008
50665-MFJ-305
ARM, L. MAIN STEP (COO)
$64.20¢32 102
1
#008
50665-MFJ-D00
ARM, L MAIN STEP
$64.20¢32 102
1
#009
50700-MFJ-D00
HOLDER, L. MAIN STEP
$85.39¢42 694
1
#9
50700-MFJ-D00
HOLDER, L. MAIN STEP
$85.39¢42 694
1
#009
50700-MFJ-D01
HOLDER, L MAIN STEP
$85.39¢42 694
1
#010
50707-MEE-000
GUARD, L. STEP
$14.46¢7 228
1
#10
50707-MEE-000
GUARD, L. STEP
$14.46¢7 228
1
#11
50718-MEE-D00
PLATE, PILLION STEP CLICK
$3.13¢1 564
1
#011
50718-MEE-D00
PLATE, PILLION STEP CLICK
$3.13¢1 564
1
#012
50720-MEL-305
ARM, R. PILLION STEP (COO)
$55.41¢27 704
1
#12
50720-MEL-305
ARM, R. PILLION STEP (COO)
$55.41¢27 704
1
#013
50730-MEL-305
ARM, L. PILLION STEP (COO)
$62.07¢31 033
1
#13
50730-MEL-305
ARM, L. PILLION STEP (COO)
$62.07¢31 033
1
#014
50750-MFJ-D00
HOLDER, R. PILLION STEP
$102.56¢51 279
1
#14
50750-MFJ-D00
HOLDER, R. PILLION STEP
$102.56¢51 279
1
#015
50760-MFJ-D00
HOLDER, L. PILLION STEP
$102.56¢51 279
1
#15
50760-MFJ-D00
HOLDER, L. PILLION STEP
$102.56¢51 279
1
#16
51486-MFJ-D00
COLLAR, STEP (LOWER)
$4.08¢2 041
1
#016
51486-MFJ-D00
COLLAR, STEP (LOWER)
$4.08¢2 041
1
#019
80119-MEL-000
RUBBER A, MOUNTING
$2.98¢1 489
1
#19
80119-MEL-000
RUBBER A, MOUNTING
$2.98¢1 489
1
#020
90157-ME9-000
BOLT, SOCKET (8X22)
$6.37¢3 186
1
#20
90157-ME9-000
BOLT, SOCKET (8X22)
$6.37¢3 186
1
#021
90118-MR1-000
SCREW, PAN (6X14)
$3.45¢1 725
1
#21
90118-MR1-000
SCREW, PAN (6X14)
$3.45¢1 725
1
#22
90502-KGB-610
COLLAR, HEAD SIDE COVER
$2.51¢1 254
1
#022
90502-KGB-610
COLLAR, HEAD SIDE COVER
$2.51¢1 254
1
#024
92501-06010-0A
BOLT, HEX. CAP (6X10)
$2.45¢1 225
1
#24
92501-06010-0A
BOLT, HEX. CAP (6X10)
$2.45¢1 225
1
#25
92501-06022-0A
BOLT, HEX. CAP (6X22)
$3.36¢1 679
1
#025
92501-06022-0A
BOLT, HEX. CAP (6X22)
$3.36¢1 679
1
#026
94101-06000
WASHER, PLAIN (6MM)
$0.77¢385
1
#26
94101-06000
WASHER, PLAIN (6MM)
$0.77¢385
1
#26
94101-06080
WASHER, PLAIN (6MM)
$0.77¢385
1
#026
94101-06080
WASHER, PLAIN (6MM)
$0.77¢385
1
#026
94101-06800
WASHER, PLAIN (6MM)
$0.77¢385
1
#26
94101-06800
WASHER, PLAIN (6MM)
$0.77¢385
1
#27
94201-16120
PIN, SPLIT (1.6X12)
$1.23¢615
1
#027
94201-16120
PIN, SPLIT (1.6X12)
$1.23¢615
1
#028
95015-83000
PIN C, PILLION STEP
$2.85¢1 426
1
#28
95015-83000
PIN C, PILLION STEP
$2.85¢1 426
1
#029
96211-08000
BALL, STEEL (#8) (1/4)
$1.47¢736
1
#29
96211-08000
BALL, STEEL (#8) (1/4)
$1.47¢736
1
