STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#1
28333-300-000
SPRING, KICK STARTER STOPPER
$3.65¢1 825
1
#2
50612-MT3-305
ARM, R. STEP (COO)
$50.56¢25 281
1
#3
50617-MJN-A00
SPRING, R. STEP RETURN
$7.46¢3 731
1
#4
50619-MT3-000
PLATE, STEP SETTING
$15.38¢7 688
1
#5
50639-ML0-010
PIN, STEP BAR
$6.14¢3 069
1
#6
50642-MT3-305
ARM, L. STEP (COO)
$57.75¢28 875
1
#7
50644-MJN-A00
SPRING, L. STEP RETURN
$7.13¢3 563
1
#8
50650-MJN-A00ZA
HOLDER, R. STEP *NH1* (BLACK)
$463.10¢231 550
1
#9
50651-MJN-A00ZB
GUARD, R. HEEL *NH1* (BLACK)
$4.77¢2 387
1
#10
50652-MJN-A00ZA
GUARD, R. STEP HEAT *NH1* (BLACK)
$12.79¢6 394
1
#11
50655-MJN-A00
STAY, R. MUFFLER SUPPORT
$22.05¢11 025
1
#12
50660-MJN-A00
GUIDE, TUBE
$7.01¢3 506
1
#13
50661-MT3-305
RUBBER, STEP (COO)
$10.25¢5 125
1
#14
50711-MT3-305
BAR, R. PILLION STEP (COO)
$75.49¢37 744
1
#15
50712-MT3-305
BAR, L PILLION STEP (COO)
$64.19¢32 094
1
#16
50718-MT3-000
PLATE, PILLION STEP CLICK
$5.99¢2 994
1
#17
50750-MJN-A00ZA
HOLDER, L. STEP *NH1* (BLACK)
$463.10¢231 550
1
#18
50751-MJN-A00ZB
GUARD, L. HEEL *NH1* (BLACK)
$4.77¢2 387
1
#19
50752-MJN-A00ZA
GUARD, L. STEP HEAT *NH1* (BLACK)
$12.79¢6 394
1
#20
50755-MJN-A00
STAY, L. MUFFLER SUPPORT
$19.04¢9 519
1
#21
53133-KR1-760
GROMMET, IGNITION COVER
$5.41¢2 706
1
#22
81520-MJN-A00
RUBBER, R. STEP
$11.03¢5 513
1
#23
81570-MJN-A00
RUBBER, L. STEP
$11.03¢5 513
1
#24
83551-GE2-000
GROMMET, AIR CLEANER HOUSING
$6.81¢3 406
1
#25
90102-MN8-700
BOLT, SOCKET (8X25)
$5.51¢2 756
1
#26
90112-MBR-J10
BOLT, SOCKET (8X34)
$4.00¢2 000
1
#27
90115-MT3-000
BOLT, MAIN STEP RUBBER SETTING
$3.49¢1 744
1
#28
90154-MEE-D00
BOLT, SOCKET (5X12)
$2.38¢1 188
1
#29
90306-MBR-000
CAP B, PIVOT
$28.21¢14 106
1
#30
90501-MC4-000
COLLAR A, AIR CLEANER HOUSING
$4.74¢2 369
1
#31
90505-MC4-000
GROMMET A, AIR CLEANER HOUSING
$3.71¢1 856
1
#32
92501-08012-0A
BOLT, CAP (8X12)
$3.94¢1 969
1
#33
93500-04010-0A
SCREW, PAN (4X10)
$1.16¢581
1
#34
93903-24180
SCREW, TAPPING (4X8)
$1.06¢531
1
#35
93903-24280
SCREW, TAPPING (4X10)
$1.74¢869
1
#36
94101-06800
WASHER, PLAIN (6MM)
$0.84¢419
1
#36
94101-06080
WASHER, PLAIN (6MM)
$0.84¢419
1
#36
94101-06000
WASHER, PLAIN (6MM)
$0.84¢419
1
#37
94101-08000
WASHER, PLAIN (8MM)
$1.06¢531
1
#38
94103-04800
WASHER, PLAIN (4MM)
$1.27¢638
1
#39
94103-06800
WASHER, PLAIN (6MM)
$1.00¢500
1
#40
94201-16120
PIN, SPLIT (1.6X12)
$1.34¢669
1
#41
94201-20150
PIN, SPLIT (2.0X15)
$1.34¢669
1
#42
94591-44000
CLIP (4X40)
$2.97¢1 487
1
#43
95015-83000
PIN C, PILLION STEP
$3.10¢1 550
1
#44
95701-06014-08
BOLT, FLANGE (6X14)
$2.09¢1 044
1
#45
95801-06025-08
BOLT, FLANGE (6X25)
$2.31¢1 156
1
#46
96001-06012-00
BOLT, FLANGE (6X12)
$2.31¢1 156
1
#47
96211-08000
BALL, STEEL (#8) (1/4)
$1.60¢800
1
#48
90514-MGH-640
COLLAR (5X2.3)
$4.88¢2 438
1
#49
77212-MFJ-D00
PROTECTOR, RUBBER
$2.24¢1 119
1
