WATER PUMP CLUTCH SLAVE CYLINDER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de WATER PUMP CLUTCH SLAVE CYLINDER

Repuestos

#1
11340-MJM-D00
COVER ASSY., L.
$182.09¢91 045
1
#2
11365-MJM-D00
PLATE, DRIVE CHAIN GUIDE
$11.05¢5 526
1
#3
11630-MJM-D00
COVER, CHANGE
$97.73¢48 864
1
#4
11632-MW4-010
GASKET, CHANGE COVER
$27.15¢13 576
1
#5
11633-MW4-000
PLATE, CHANGE COVER
$14.33¢7 165
1
#6
19200-MJM-D00
WATER PUMP
$290.25¢145 124
1
#7
19220-MJM-D00
COVER, WATER PUMP
$120.28¢60 139
1
#8
19226-MCP-900
GASKET, WATER PUMP COVER
$4.24¢2 122
1
#9
22860-MCW-000
CYLINDER ASSY., CLUTCH SLAVE
$143.57¢71 783
1
#10
22862-MGJ-D00
GASKET, SLAVE CYLINDER
$5.55¢2 777
1
#11
22863-MG9-003
PISTON, SLAVE CYLINDER
$31.04¢15 519
1
#12
22864-MT7-016
SPRING, SLAVE CYLINDER
$6.92¢3 461
1
#13
22865-MG9-003
CUP
$13.43¢6 716
1
#14
22866-MF2-711
SCREW, BLEEDER
$5.70¢2 852
1
#15
43353-461-771
CAP, BLEEDER
$5.63¢2 818
1
#16
90006-GHB-610
BOLT, FLANGE (6X12) (NSHF)
$2.28¢1 138
1
#17
90006-GHB-660
BOLT, FLANGE (6X22) (NSHF)
$2.13¢1 064
1
#18
90006-GHB-680
BOLT, FLANGE (6X28) (NSHF)
$2.42¢1 208
1
#19
90006-GHB-700
BOLT, FLANGE (6X35) (NSHF)
$2.28¢1 138
1
#20
90006-GHB-780
BOLT, FLANGE (6X75) (NSHF)
$2.42¢1 208
1
#21
90011-GHB-650
BOLT, FLANGE (6X20)
$2.13¢1 064
1
#22
90011-GHB-700
BOLT, FLANGE (6X35)
$2.13¢1 064
1
#23
90011-GHB-820
BOLT, FLANGE (6X95)
$3.22¢1 610
1
#24
90013-883-000
BOLT, FLANGE (6X12) (CT200)
$1.75¢874
1
#25
90121-MV9-670
BOLT, FLANGE (6X25)
$3.36¢1 679
1
#26
90463-ML7-000
WASHER, SEALING (6.5MM)
$3.36¢1 679
1
#27
91101-121-691
BEARING, NEEDLE (14MM) (TOYO)
$29.03¢14 513
1
#28
91203-KK3-830
OIL SEAL (14X22X5)
$4.25¢2 128
1
#29
91209-MB0-003
OIL SEAL (8X18X5)
$4.52¢2 260
1
#30
91302-MB0-013
O-RING (32.95X2.62) (ARAI)
$3.36¢1 679
1
#31
94301-08140
PIN, DOWEL (8X14)
$2.66¢1 328
1
