CONTROL UNIT AIRBAG

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de CONTROL UNIT AIRBAG

Repuestos

#1
16712-MN5-000
RUBBER, FUEL PUMP STOPPER
$3.73¢1 863
1
#001
16712-MN5-000
RUBBER, FUEL PUMP STOPPER
$3.73¢1 863
1
#002
30401-MCA-000
CUSHION, REVERSE REGULATOR
$7.69¢3 844
1
#2
30401-MCA-000
CUSHION, REVERSE REGULATOR
$7.69¢3 844
1
#3
31710-MCA-S41
REGULATOR, REVERSE
$184.11¢92 056
1
#003
31710-MCA-S41
REGULATOR, REVERSE
$184.11¢92 056
1
#4
32170-KR5-000
CLIP, WIRE HARNESS
$1.79¢894
1
#004
32170-KR5-000
CLIP, WIRE HARNESS
$1.79¢894
1
#5
36280-MCA-A61
RESISTOR ASSY., REVERSE
$274.57¢137 288
1
#005
36280-MCA-A61
RESISTOR ASSY., REVERSE
$274.57¢137 288
1
#006
36700-MCA-S41
CONTROLLER, AUTO CRUISE
$759.86¢379 931
1
#6
36700-MCA-S41
CONTROLLER, AUTO CRUISE
$759.86¢379 931
1
#007
37830-MEL-003
SENSOR ASSY., MAP
$150.09¢75 044
1
#7
37830-MEL-003
SENSOR ASSY., MAP
$150.09¢75 044
1
#008
38110-MCA-003
HORN ASSY. (HIGH)
$114.86¢57 431
1
#8
38110-MCA-003
HORN ASSY. (HIGH)
$114.86¢57 431
1
#009
38120-MCA-003
HORN ASSY. (LOW)
$114.86¢57 431
1
#9
38120-MCA-003
HORN ASSY. (LOW)
$114.86¢57 431
1
#10
38301-KTF-671
RELAY, TURN SIGNAL
$42.41¢21 206
1
#010
38301-KTF-671
RELAY, TURN SIGNAL
$42.41¢21 206
1
#11
38306-KK4-000
SUSPENSION, TURN SIGNAL RELAY (MITSUBA)
$3.65¢1 825
1
#011
38306-KK4-000
SUSPENSION, TURN SIGNAL RELAY (MITSUBA)
$3.65¢1 825
1
#012
38380-MCA-S41
CONTROL UNIT, TRUNK LOCK OPEN
No Disponible
1
#12
38380-MCA-S41
CONTROL UNIT, TRUNK LOCK OPEN
No Disponible
1
#013
38600-MCA-A71
ABS CONTROL UNIT
$1271.70¢635 850
1
#13
38600-MCA-A71
ABS CONTROL UNIT
$1271.70¢635 850
1
#14
38605-MCA-A80
CUSHION, ABS CONTROL UNIT
$27.07¢13 538
1
#014
38605-MCA-A80
CUSHION, ABS CONTROL UNIT
$27.07¢13 538
1
#015
38770-MCA-R63
PGM-FI UNIT
$1854.94¢927 469
1
#15
38770-MCA-R63
PGM-FI UNIT
$1854.94¢927 469
1
#015
38770-MCA-R64
UNIT COMP PGM-FI/IGN
$1854.94¢927 469
1
#16
38775-MCA-S40
TRAY, AUTO CRUISE UNIT
$20.41¢10 206
1
#016
38775-MCA-S40
TRAY, AUTO CRUISE UNIT
$20.41¢10 206
1
#017
39305-MCA-S41
HEATER UNIT, SEAT
$352.30¢176 150
1
#17
39305-MCA-S41
HEATER UNIT, SEAT
$352.30¢176 150
1
#018
39310-MCA-A71
CUSHION, SEAT HEATER UNIT
$5.90¢2 950
1
#18
39310-MCA-A71
CUSHION, SEAT HEATER UNIT
$5.90¢2 950
1
#19
50331-MCA-S40
STAY, REVERSE RESISTOR
$41.90¢20 950
1
#019
50331-MCA-S40
STAY, REVERSE RESISTOR
$41.90¢20 950
1
#20
64513-MCA-A60
PLATE, STAY (UPPER)
$6.86¢3 431
1
#020
64513-MCA-A60
PLATE, STAY (UPPER)
$6.86¢3 431
1
#021
77218-GB2-720
RUBBER, SEAT HINGE
$3.44¢1 719
1
#21
77218-GB2-720
RUBBER, SEAT HINGE
$3.44¢1 719
1
#022
77835-MCA-A80
STAY ASSY., RETAINER
$48.49¢24 244
1
#22
77835-MCA-A80
STAY ASSY., RETAINER
$48.49¢24 244
1
#23
77960-MCA-S81
OR USE TL CONNECT TO ORDER)
$871.29¢435 644
1
#023
77960-MCA-S81
OR USE TL CONNECT TO ORDER)
$871.29¢435 644
1
#24
77961-MCA-A80
HOLDER A, CONNECTOR COVER
$7.52¢3 762
1
#024
77961-MCA-A80
HOLDER A, CONNECTOR COVER
$7.52¢3 762
1
#025
77962-MCA-A80
HOLDER B, CONNECTOR COVER
$77.81¢38 906
1
#25
77962-MCA-A80
HOLDER B, CONNECTOR COVER
$77.81¢38 906
1
#26
81215-MZ0-700
SEAL, SADDLEBAG
$1.70¢850
1
#026
81215-MZ0-700
SEAL, SADDLEBAG
$1.70¢850
1
#27
83551-376-000
GROMMET, SIDE COVER
$3.65¢1 825
1
#027
83551-376-000
GROMMET, SIDE COVER
$3.65¢1 825
1
#28
90512-MBY-000
WASHER (6X20)
$6.34¢3 169
1
#028
90512-MBY-000
WASHER (6X20)
$6.34¢3 169
1
#29
91411-679-000
CLIP
$20.86¢10 431
1
#029
91411-679-000
CLIP
$20.86¢10 431
1
#030
91413-679-000
CLIP (2X70)
$10.81¢5 406
1
#30
91413-679-000
CLIP (2X70)
$10.81¢5 406
1
#31
91556-SP0-003
CLIP, CONNECTOR (BROWN)
$6.47¢3 238
1
#031
91556-SP0-003
CLIP, CONNECTOR (BROWN)
$6.47¢3 238
1
#032
93500-04025-0A
SCREW, PAN (4X25)
$2.30¢1 150
1
#32
93500-04025-0A
SCREW, PAN (4X25)
$2.30¢1 150
1
#033
93892-05008-08
SCREW-WASHER (5X8)
$1.35¢675
1
#33
93892-05008-08
SCREW-WASHER (5X8)
$1.35¢675
1
#034
93903-25280
SCREW, TAPPING (5X12)
$1.66¢831
1
#34
93903-25280
SCREW, TAPPING (5X12)
$1.66¢831
1
#35
93903-25480
SCREW, TAPPING (5X20)
$0.86¢431
1
#035
93903-25480
SCREW, TAPPING (5X20)
$0.86¢431
1
#36
94050-06080
NUT, FLANGE (6MM)
$0.80¢400
1
#036
94050-06080
NUT, FLANGE (6MM)
$0.80¢400
1
#37
95005-14001-30M
BULK HOSE, VACUUM (14X1000) (14X50)
No Disponible
1
#037
95005-14001-30M
BULK HOSE, VACUUM (14X1000) (14X50)
No Disponible
1
#38
95701-06012-00
BOLT, FLANGE (6X12)
$2.09¢1 044
1
#038
95701-06012-00
BOLT, FLANGE (6X12)
$2.09¢1 044
1
#039
95701-06016-00
BOLT, FLANGE (6X16)
$2.09¢1 044
1
#39
95701-06016-00
BOLT, FLANGE (6X16)
$2.09¢1 044
1
#040
95701-06018-08
BOLT, FLANGE (6X18)
$2.09¢1 044
1
#40
95701-06018-08
BOLT, FLANGE (6X18)
$2.09¢1 044
1
#41
95701-08016-08
BOLT, FLANGE (8X16)
$2.15¢1 075
1
#041
95701-08016-08
BOLT, FLANGE (8X16)
$2.15¢1 075
1
#42
96001-06016-00
BOLT, FLANGE (6X16)
$1.35¢675
1
#042
96001-06016-00
BOLT, FLANGE (6X16)
$1.35¢675
1
#043
96001-06016-07
BOLT, FLANGE (6X16)
$1.35¢675
1
#43
96001-06016-07
BOLT, FLANGE (6X16)
$1.35¢675
1
