UPPER COWL

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de UPPER COWL

Repuestos

#001
53133-KR1-760
GROMMET, IGNITION COVER
$5.41¢2 706
1
#003
61403-MKR-D10
PROTECTOR, WIND
$27.03¢13 513
1
#004
64125-MKR-D10ZC
COVER, IN. (LOWER) (TYPE1)
$141.96¢70 981
1
#005
64130-MKR-D10
PANEL, IN. (LOWER)
$12.25¢6 125
1
#006
64200-MKR-D80ZA
COWL SET, Front. (UPPER) (TYPE1) (WL)
$291.39¢145 694
1
#009
64250-MKR-D10ZA
WINDSCREEN SET (TYPE1) (WL)
$247.75¢123 875
1
#010
64501-MKR-D10
STAY ASSY., COWL (UPPER)
$102.38¢51 188
1
#011
90026-GHB-610
BOLT, FLANGE (6X10)
$2.88¢1 438
1
#013
90102-MKA-D80
SCREW, SPECIAL (5X14)
$3.65¢1 825
1
#014
90110-MGB-Y00
NUT, WELL (4MM)
$5.07¢2 537
1
#015
90116-MFL-D20
SCREW, SPECIAL (6X16)
$3.34¢1 669
1
#016
90116-SP0-003
CLIP, BUMPER SEAL
$5.72¢2 863
1
#017
90118-MKR-D10
BOLT, SPECIAL (4X14)
$2.89¢1 444
1
#018
90505-MKR-D10
WASHER, THRUST (4MM)
$1.80¢900
1
#019
90506-MKR-D10
WASHER, SCREEN SETTING
$1.74¢869
1
#020
90677-KAN-961
NUT, CLIP (5MM)
$4.94¢2 469
1
#021
17380-MKR-A30
GRILL, AIR IN. DUCT
$21.25¢10 625
1
