STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#001
28333-300-000
SPRING, KICK STARTER STOPPER
$3.36¢1 679
1
#002
50600-K0A-DB0
HOLDER, R. STEP
$13.78¢6 889
1
#003
50603-K94-T00
PIN, STEP BAR JOINT
$4.70¢2 352
1
#004
50603-KB4-000
PIN, STEP BAR JOINT
$5.73¢2 864
1
#005
50610-K15-900
RUBBER, MAIN STEP
$1.12¢558
1
#006
50612-K0A-DB0
BRACKET, MAIN STEP
$2.77¢1 386
1
#007
50613-K0A-DB0
PLATE, STEP SETTING
$1.83¢914
1
#008
50617-445-840
SPRING, R. STEP RETURN
$6.08¢3 042
1
#009
50635-K1L-D00
ARM, R. MAIN STEP
$2.96¢1 478
1
#010
50644-445-840
SPRING, L. STEP RETURN
$6.08¢3 042
1
#011
50645-K1L-D00
ARM, L. MAIN STEP
$2.96¢1 478
1
#012
50700-K0A-DB0
HOLDER, L. STEP
$12.94¢6 469
1
#013
50715-K0A-DB0
HOLDER, R. PILLION STEP
$14.18¢7 090
1
#014
50716-K0A-DB0
COVER, PILLION STEP
$0.11¢57
1
#015
50718-MN8-000
PLATE, PILLION STEP CLICK
$2.94¢1 472
1
#016
50720-K0A-DB0
ARM, R. PILLION STEP
$4.81¢2 403
1
#017
50725-K0A-DB0
HOLDER, L. PILLION STEP
$13.68¢6 842
1
#018
50730-K0A-DB0
ARM, L. PILLION STEP
$4.81¢2 403
1
#019
90106-K94-T00
BOLT, SOCKET (8X20)
$1.45¢724
1
#020
90108-K15-900
BOLT, SPECIAL (5X14)
$0.55¢276
1
#021
90131-KWN-900
BOLT, FLANGE (8X28)
$1.09¢546
1
#022
90161-K94-T00
BOLT, SOCKET (8X22)
$1.45¢724
1
#023
90311-K15-900
COLLAR (6MM)
$0.11¢57
1
#024
90502-K94-T00
WASHER (15.5X27X2.0)
$1.41¢707
1
#025
90503-K94-T00
WASHER (8.5X22X2.0)
$1.44¢719
1
#026
92501-06016-0A
BOLT, CAP (6X16)
$3.36¢1 679
1
#027
94102-08000
WASHER, PLAIN (8MM)
$1.06¢529
1
#028
94201-16150
PIN, SPLIT (1.6X15)
$1.23¢615
1
#028
94201-16250
PIN, COTTER (1.6X25)
$1.23¢615
1
#029
96211-08000
BALL, STEEL (#8) (1/4)
$1.47¢736
1
