STARTING MOTOR 2

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STARTING MOTOR 2

Repuestos

#001
22838-MY6-880
RECEIVER, CLUTCH CABLE
$19.46¢9 729
1
#002
31031-MK5-010
RUBBER, STARTER MOTOR
$3.89¢1 943
1
#003
31190-MK4-600
SPACER
$28.81¢14 404
1
#004
31200-MN9-023
STARTER MOTOR Assembly.
$547.14¢273 568
1
#005
31201-MEW-921
BRUSH SET A, CARBON
$8.68¢4 341
1
#006
31202-MEW-921
BRUSH SET B, CARBON
$13.98¢6 992
1
#007
31203-MEW-921
HOLDER, BRUSH
$8.35¢4 174
1
#008
31204-MEW-921
SPRING, CARBON BRUSH
$13.58¢6 791
1
#009
31205-HP5-601
BOLT, SETTING
$3.27¢1 633
1
#010
31206-MEW-921
BOLT, TERMINAL
$3.36¢1 679
1
#011
31207-HP5-601
RING
$2.54¢1 271
1
#012
31208-MEW-921
INSULATOR
$9.07¢4 537
1
#013
31209-MEW-921
STOPPER, TERMINAL
$13.45¢6 727
1
#014
31210-MEW-921
WASHER
$2.15¢1 075
1
#015
32410-MY6-671
CABLE, STARTER MOTOR
$35.05¢17 526
1
#016
32601-MY6-670
CABLE, BATTERY GROUND
$55.29¢27 646
1
#017
90004-GHB-630
BOLT, FLANGE (6X16) (NSHF)
$3.91¢1 955
1
#018
90071-MB0-000
NUT-WASHER (6MM)
$2.45¢1 225
1
#019
91309-425-003
O-RING (24.4X3.1) (ARAI)
$6.96¢3 479
1
#019
91312-MG7-003
O-RING (24.4X3.1)
$6.96¢3 479
1
#020
91320-MB0-000
O-RING (4X2)
$2.86¢1 432
1
#021
93892-05012-08
SCREW-WASHER (5X12)
$1.36¢678
1
#022
94520-32000
CIRCLIP (INNER) (32MM)
$2.09¢1 047
1
#023
95701-06055-00
BOLT, FLANGE (6X55)
$2.45¢1 225
1
#024
96100-62010-00
BEARING, RADIAL BALL (6201)
$9.02¢4 508
1
