STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#1
18421-KR3-000
RUBBER B, MUFFLER MOUNTING
$7.01¢3 507
1
#001
18421-KR3-000
RUBBER B, MUFFLER MOUNTING
$7.01¢3 507
1
#2
35700-KEB-306
SWITCH SET, SIDE STAND
No Disponible
1
#002
35700-KEB-306
SWITCH SET, SIDE STAND
No Disponible
1
#2
35700-MBA-305
SWITCH SET, SIDE STAND
No Disponible
1
#003
50530-KR3-305
BAR, SIDE STAND (COO)
$76.58¢38 289
1
#3
50530-KR3-305
BAR, SIDE STAND (COO)
$76.58¢38 289
1
#003
50530-KR3-870
BAR, SIDE STAND
$76.58¢38 289
1
#3
50530-KR3-870
BAR, SIDE STAND
$76.58¢38 289
1
#004
50543-KR3-000
SPRING D, SIDE STAND
$8.79¢4 393
1
#4
50543-KR3-000
SPRING D, SIDE STAND
$8.79¢4 393
1
#005
50600-KEB-900
BRACKET, R. MAIN STEP
$70.92¢35 460
1
#5
50600-KEB-900
BRACKET, R. MAIN STEP
$70.92¢35 460
1
#006
50603-MC4-000
PIN, STEP BAR JOINT
$5.22¢2 610
1
#6
50603-MC4-000
PIN, STEP BAR JOINT
$5.22¢2 610
1
#007
50605-KEB-950
BRACKET, L. MAIN STEP
$70.92¢35 460
1
#7
50605-KEB-950
BRACKET, L. MAIN STEP
$70.92¢35 460
1
#8
50614-KR3-J00
RUBBER, STEP STOPPER
$3.79¢1 897
1
#008
50614-KR3-J00
RUBBER, STEP STOPPER
$3.79¢1 897
1
#9
50616-KR3-J00
STEP, R.
$44.06¢22 028
1
#009
50616-KR3-J00
STEP, R.
$44.06¢22 028
1
#010
50617-KR3-J00
STEP, Left
$44.06¢22 028
1
#10
50617-KR3-J00
STEP, Left
$44.06¢22 028
1
#11
50619-KR3-770
STOPPER, STEP RUBBER
$15.92¢7 958
1
#011
50619-KR3-770
STOPPER, STEP RUBBER
$15.92¢7 958
1
#12
50622-KG1-000
COLLAR, STEP SETTING
$9.54¢4 773
1
#012
50622-KG1-000
COLLAR, STEP SETTING
$9.54¢4 773
1
#13
50634-KR3-000
SPRING, Right STEP RETURN
$6.61¢3 306
1
#013
50634-KR3-000
SPRING, Right STEP RETURN
$6.61¢3 306
1
#14
50644-KR3-000
SPRING, L STEP RETURN
$6.55¢3 278
1
#014
50644-KR3-000
SPRING, L STEP RETURN
$6.55¢3 278
1
#15
50661-KR3-305
RUBBER, MAIN STEP (COO)
$10.99¢5 497
1
#015
50661-KR3-305
RUBBER, MAIN STEP (COO)
$10.99¢5 497
1
#15
50661-KR3-000
RUBBER, MAIN STEP
$10.99¢5 497
1
#015
50661-KR3-000
RUBBER, MAIN STEP
$10.99¢5 497
1
#016
50710-461-305
RUBBER, PILLION STEP (COO)
$13.65¢6 825
1
#16
50710-461-305
RUBBER, PILLION STEP (COO)
$13.65¢6 825
1
#016
50710-461-770
RUBBER, PILLION STEP
$13.65¢6 825
1
#16
50710-461-770
RUBBER, PILLION STEP
$13.65¢6 825
1
#017
50712-438-730
WASHER, R. PILLION STEP
$6.58¢3 289
1
#17
50712-438-730
WASHER, R. PILLION STEP
$6.58¢3 289
1
#18
50713-KR3-000
BRACKET, R. PILLION STEP
No Disponible
1
#18
50713-KR3-770
BRACKET, R. PILLION STEP
No Disponible
1
#18
50713-KR3-950ZA
BRACKET, R. PILLION STEP
No Disponible
1
#018
50713-KR3-000
BRACKET, R. PILLION STEP
No Disponible
1
#019
50713-438-730
WASHER, L. PILLION STEP
$6.58¢3 289
1
#19
50713-438-730
WASHER, L. PILLION STEP
$6.58¢3 289
1
#020
50714-KR3-000
BRACKET, L. PILLION STEP
No Disponible
1
#20
50714-KR3-000
BRACKET, L. PILLION STEP
No Disponible
1
#20
50714-KR3-770
BRACKET, L. PILLION STEP
No Disponible
1
#20
50714-KR3-950ZA
BRACKET, L. PILLION STEP
No Disponible
1
#021
50715-461-770
BAR, R. PILLION STEP
$44.21¢22 103
1
#21
50715-461-770
BAR, R. PILLION STEP
$44.21¢22 103
1
#22
50716-KR3-000
COLLAR, PILLION STEP
$7.03¢3 513
1
#022
50716-KR3-000
COLLAR, PILLION STEP
$7.03¢3 513
1
#023
50718-461-770
BAR, L. PILLION STEP
$44.21¢22 103
1
#23
50718-461-770
BAR, L. PILLION STEP
$44.21¢22 103
1
#024
61309-303-810
COLLAR, BUZZER SETTING
$5.76¢2 881
1
#24
61309-303-810
COLLAR, BUZZER SETTING
$5.76¢2 881
1
#025
90108-MK6-670
BOLT, SIDE STAND PIVOT
$8.68¢4 341
1
#25
90108-MK6-670
BOLT, SIDE STAND PIVOT
$8.68¢4 341
1
#026
90129-KR3-740
BOLT, FLANGE (8X30)
$4.86¢2 432
1
#26
90129-KR3-740
BOLT, FLANGE (8X30)
$4.86¢2 432
1
#027
90130-KR3-740
BOLT, FLANGE (10X34)
$6.58¢3 289
1
#27
90130-KR3-740
BOLT, FLANGE (10X34)
$6.58¢3 289
1
#028
90147-MCE-950
BOLT, SPECIAL (6X16)
$0.66¢328
1
#28
90147-MCE-950
BOLT, SPECIAL (6X16)
$0.66¢328
1
#029
90203-MF9-710
NUT, SIDE STAND
$4.08¢2 041
1
#29
90203-MF9-710
NUT, SIDE STAND
$4.08¢2 041
1
#30
92101-06016-0A
BOLT, HEX. (6X16)
$1.66¢828
1
#030
92101-06016-0A
BOLT, HEX. (6X16)
$1.66¢828
1
#31
94101-06080
WASHER, PLAIN (6MM)
$0.77¢385
1
#031
94101-06800
WASHER, PLAIN (6MM)
$0.77¢385
1
#31
94101-06800
WASHER, PLAIN (6MM)
$0.77¢385
1
#031
94101-06080
WASHER, PLAIN (6MM)
$0.77¢385
1
#31
94101-06000
WASHER, PLAIN (6MM)
$0.77¢385
1
#031
94101-06000
WASHER, PLAIN (6MM)
$0.77¢385
1
#32
94101-08000
WASHER, PLAIN (8MM)
$0.98¢489
1
#032
94101-08000
WASHER, PLAIN (8MM)
$0.98¢489
1
#33
94201-16150
PIN, SPLIT (1.6X15)
$1.23¢615
1
#033
94201-16150
PIN, SPLIT (1.6X15)
$1.23¢615
1
#033
94201-16250
PIN, COTTER (1.6X25)
$1.23¢615
1
#33
94201-16250
PIN, COTTER (1.6X25)
$1.23¢615
1
#34
95015-81000
PIN A, PILLION STEP
$2.62¢1 311
1
#034
95015-81000
PIN A, PILLION STEP
$2.62¢1 311
1
