TOP SHELTER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de TOP SHELTER

Repuestos

#001
17227-GS3-000
RUBBER, AIR CLEANER MOUNTING
$3.69¢1 844
1
#002
33181-MBB-000
RUBBER, POSITION LIGHT
$5.75¢2 875
1
#003
33712-GC6-000
COLLAR, TAILLIGHT
$3.65¢1 825
1
#004
64121-MEL-000
RUBBER, PROTECTOR
$2.63¢1 313
1
#005
64503-MFL-000
BADGE, R. PRODUCT
$44.65¢22 325
1
#006
64508-MFL-000
BADGE, L. PRODUCT
$44.65¢22 325
1
#007
83150-MGP-D00ZD
SHELTER SET, TOP (TYPE1) (WL)
$1512.73¢756 363
1
#008
83165-MGP-D00
COVER, R. AIR CLEANER SIDE
$35.64¢17 819
1
#009
83166-MGP-D00
COVER, L. AIR CLEANER SIDE
$35.64¢17 819
1
#010
83551-GE2-000
GROMMET, AIR CLEANER HOUSING
$6.81¢3 406
1
#011
83600-MGP-D00ZB
COVER, Right SIDE R334 (VICTORY RED)
$30.58¢15 288
1
#013
83700-MGP-D00ZB
COVER, L SIDE R334 (VICTORY RED)
$30.58¢15 288
1
#015
90115-MFL-D20
SCREW, PAN (6X20)
$2.64¢1 319
1
#016
90502-KGB-610
COLLAR, HEAD SIDE COVER
$2.73¢1 363
1
#017
93903-24280
SCREW, TAPPING (4X10)
$1.74¢869
1
