SHELTER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de SHELTER

Repuestos

#001
17227-GS3-000
RUBBER, AIR CLEANER MOUNTING
$3.69¢1 844
1
#002
17516-KCZ-000ZB
TRIM, FUEL TANK NH1 (BLACK)
$2.60¢1 300
1
#003
33181-MBB-000
RUBBER, POSITION LIGHT
$5.75¢2 875
1
#004
38117-MGZ-J00
COLLAR, HORN SETTING
$2.24¢1 119
1
#005
39965-MKF-D40
COVER, INERTIAL MEASUREMENT UNIT
$23.95¢11 975
1
#006
64213-MJN-A01
CLIP, TWIST
$2.52¢1 263
1
#007
80102-MJS-J70
RUBBER, RR. FENDER
$2.03¢1 013
1
#008
83150-MKF-D70ZB
SHELTER SET, RR. (TYPE1) (WL)
$1211.39¢605 694
1
#009
83153-MKF-D60ZA
SHELTER SET, FR. (TYPE1) (WL)
$42.64¢21 319
1
#011
83160-MKF-D70ZA
SHELTER SET, R. SIDE *R334* (WL)(VICTORY RED)
$292.13¢146 063
1
#012
83165-MKF-D40ZA
COVER, R. AIR CLEANER SIDE *NH1*(BLACK)
$22.27¢11 138
1
#013
83166-MKF-D40ZA
COVER, L. AIR CLEANER SIDE *NH1*(BLACK)
$22.27¢11 138
1
#014
83170-MKF-D70ZA
SHELTER SET, L. SIDE *R334* (WL)(VICTORY RED)
$292.13¢146 063
1
#015
86211-MJK-N20
BADGE, R. PRODUCT
$43.67¢21 838
1
#016
86212-MJK-N20
BADGE, L. PRODUCT
$43.67¢21 838
1
#017
90115-MFL-D20
SCREW, PAN (6X20)
$2.64¢1 319
1
#018
90502-KGB-610
COLLAR, HEAD SIDE COVER
$2.73¢1 363
1
#019
90852-446-630
PLUG, HOLE
$3.30¢1 650
1
