CLUTCH

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de CLUTCH

Repuestos

#001
14311-K31-900
SPROCKET, TIMING (17T)
$28.04¢14 018
1
#002
22100-K99-A01
CLUTCH OUTER
$149.80¢74 899
1
#003
22116-K31-900
GUIDE, CLUTCH (OUTER)
$12.30¢6 152
1
#004
22121-K99-A01
CENTER, CLUTCH
$17.31¢8 654
1
#005
22125-ML7-000
SEAT, JUDDER SPRING
$11.49¢5 744
1
#006
22201-HM3-A60
DISK, CLUTCH FRICTION
$15.89¢7 946
1
#007
22202-MAE-000
DISK B, CLUTCH FRICTION
$17.10¢8 550
1
#008
22321-ML7-000
PLATE, CLUTCH
$15.08¢7 538
1
#009
22350-K99-A01
PLATE, CLUTCH PRESSURE
$14.63¢7 314
1
#010
22401-K99-A01
SPRING, CLUTCH
$3.36¢1 679
1
#011
22402-K99-A00
SPRING, JUDDER
$16.19¢8 096
1
#012
22847-K31-901
PIN, CLUTCH LIFTER
$21.70¢10 850
1
#013
23121-K31-900
GEAR, PRIMARY DRIVE (22T)
$45.88¢22 943
1
#014
90050-K31-901
BOLT-WASHER (6X25)
$2.81¢1 403
1
#015
90201-KYJ-900
NUT, SPECIAL (16MM)
$3.98¢1 989
1
#016
90235-K31-900
NUT, LOCK (16MM)
$8.26¢4 129
1
#017
90404-KVK-900
WASHER (20X40X2)
$3.36¢1 679
1
#018
90434-K31-900
WASHER (19MM)
$8.23¢4 117
1
#019
90434-KPS-900
WASHER (16MM)
$2.36¢1 179
1
#020
91012-K31-901
BEARING, NEEDLE (28X33X16.8)
$17.55¢8 775
1
