STARTING MOTOR 2

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STARTING MOTOR 2

Repuestos

#001
22838-MY6-880
RECEIVER, CLUTCH CABLE
$21.15¢10 575
1
#002
31031-MK5-010
RUBBER, STARTER MOTOR
$4.22¢2 113
1
#003
31190-MK4-600
SPACER
$31.31¢15 656
1
#004
31200-MN9-023
STARTER MOTOR Assembly.
$594.71¢297 356
1
#005
31201-MEW-921
BRUSH SET A, CARBON
$9.44¢4 719
1
#006
31202-MEW-921
BRUSH SET B, CARBON
$15.20¢7 600
1
#007
31203-MEW-921
HOLDER, BRUSH
$9.07¢4 538
1
#008
31204-MEW-921
SPRING, CARBON BRUSH
$14.76¢7 381
1
#009
31205-HP5-601
BOLT, SETTING
$3.55¢1 775
1
#010
31206-MEW-921
BOLT, TERMINAL
$3.65¢1 825
1
#011
31207-HP5-601
RING
$2.76¢1 381
1
#012
31208-MEW-921
INSULATOR
$9.86¢4 931
1
#013
31209-MEW-921
STOPPER, TERMINAL
$14.63¢7 313
1
#014
31210-MEW-921
WASHER
$2.34¢1 169
1
#015
32410-MY6-671
CABLE, STARTER MOTOR
$38.10¢19 050
1
#016
32601-MY6-670
CABLE, BATTERY GROUND
$60.10¢30 050
1
#017
90004-GHB-630
BOLT, FLANGE (6X16) (NSHF)
$4.25¢2 125
1
#018
90071-MB0-000
NUT-WASHER (6MM)
$2.66¢1 331
1
#019
91309-425-003
O-RING (24.4X3.1) (ARAI)
$7.56¢3 781
1
#019
91312-MG7-003
O-RING (24.4X3.1)
$7.56¢3 781
1
#020
91320-MB0-000
O-RING (4X2)
$3.11¢1 556
1
#021
93892-05012-08
SCREW-WASHER (5X12)
$1.47¢737
1
#022
94520-32000
CIRCLIP (INNER) (32MM)
$2.27¢1 138
1
#023
95701-06055-00
BOLT, FLANGE (6X55)
$2.66¢1 331
1
#024
96100-62010-00
BEARING, RADIAL BALL (6201)
$9.80¢4 900
1
