CLUTCH

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.

Repuestos

#001

13115-147-000

CLIP, PISTON PIN (10MM)

$2.62¢1 311

#002

22100-MKE-A00

CLUTCH OUTER

$465.90¢232 950

#003

22106-KS7-000

COLLAR, CLUTCH (OUTER)

$28.14¢14 070

#004

22120-MKE-A00

CENTER, CLUTCH

$103.07¢51 537

#005

22125-MBN-670

SEAT, JUDDER SPRING

$9.04¢4 520

#006

22201-MBN-670

DISK, CLUTCH FRICTION

$21.59¢10 793

#007

22201-MEN-670

DISK B, CLUTCH FRICTION

$15.69¢7 843

#008

22201-MEN-A10

DISK, CLUTCH FRICTION

$16.33¢8 165

#009

22321-MKE-A00

PLATE B, CLUTCH

$14.54¢7 268

#010

22351-MKE-A70

PLATE, CLUTCH PRESSURE

$74.64¢37 318

#011

22352-MKE-A70

PIECE, CLUTCH LIFTER

$51.09¢25 547

#012

22401-MEN-A80

SPRING, CLUTCH

$5.30¢2 651

#013

22402-MBN-670

SPRING, JUDDER

$22.78¢11 391

#014

22850-MKE-A00

ROD, CLUTCH LIFTER

$72.16¢36 081

#015

23121-MKE-A00

GEAR, PRIMARY DRIVE (28T)

$86.97¢43 487

#016

90013-MEY-670

BOLT, SPECIAL (12X47)

$7.83¢3 916

#017

90024-MEN-A70

BOLT-WASHER (6X35)

$2.86¢1 432

#018

90235-MEN-A30

NUT (18MM)

$5.73¢2 864

#019

90401-MKE-A70

WASHER (12.1X25X1)

$2.75¢1 374

#020

90402-KW6-960

WASHER, PLAIN (12MM)

$6.20¢3 099

#021

90421-MKE-A00

WASHER (23X48X2)

$8.22¢4 111

#022

90461-KZ3-J10

WASHER, LOCK (18MM)

$6.97¢3 484

#023

90501-ML3-910

WASHER (18X32X2)

$4.88¢2 438

#024

91001-147-003

BEARING, NEEDLE (12MM) (NTN)

$13.43¢6 716

#025

91021-ML3-003

BEARING, NEEDLE (28X32X27.2) (THOMPSON)

$19.23¢9 614
