TOP SHELTER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de TOP SHELTER

Repuestos

#001
64121-MEL-000
RUBBER, PROTECTOR
$2.42¢1 208
1
#002
64315-MJC-A00
COVER, R. MIDDLE
$22.34¢11 172
1
#003
64365-MJC-A00
COVER, L. MIDDLE
$22.34¢11 172
1
#004
64535-MFJ-D00
RUBBER, SIDE COVER
$2.30¢1 150
1
#005
80101-165-000
RUBBER, Rear FENDER CUSHION
$4.16¢2 081
1
#006
83100-MJC-N40ZA
SHELTER Assembly., TOP (TYPE1) (WL)
$1231.56¢615 779
1
#007
83161-MFJ-A00
MAT, R. RR. TOP SHELTER
$12.18¢6 089
1
#008
83162-MFJ-A00
MAT, L. RR. TOP SHELTER
$12.18¢6 089
1
#009
83165-MFJ-A00
(BOTH SIDES)
$10.94¢5 468
1
#010
83601-MJC-A00ZE
COVER, R. SIDE *NHA86M*(MAT BALLISTIC BLACK)
$136.02¢68 011
1
#011
83701-MJC-A00ZE
COVER, L SIDE NHA86M (MAT BALLISTIC BLACK)
$142.15¢71 076
1
#012
84706-163-670
COLLAR, TAILLIGHT MOUNTING
$4.55¢2 277
1
#013
86211-MJK-N20
BADGE, R. PRODUCT
$40.18¢20 091
1
#014
86212-MJK-N20
BADGE, L. PRODUCT
$40.18¢20 091
1
#015
90106-MBY-000
SCREW, SPECIAL (5X12)
$3.16¢1 581
1
#016
90114-MFJ-D00
SCREW, SPECIAL (5X6)
$2.53¢1 265
1
#017
90118-MEJ-J00
SCREW, PAN (6X20)
$2.53¢1 265
1
#018
90677-KAN-961
NUT, CLIP (5MM)
$4.54¢2 271
1
#019
90683-GR1-003
CLIP, BODY COVER
$3.36¢1 679
1
#020
93903-24280
SCREW, TAPPING (4X10)
$1.60¢799
1
