SHELTER

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de SHELTER

Repuestos

#001
17227-GS3-000
RUBBER, AIR CLEANER MOUNTING
$3.39¢1 696
1
#002
17516-KCZ-000ZB
TRIM, FUEL TANK NH1 (BLACK)
$2.39¢1 196
1
#003
33181-MBB-000
RUBBER, POSITION LIGHT
$5.29¢2 645
1
#004
38117-MGZ-J00
COLLAR, HORN SETTING
$2.06¢1 029
1
#005
39965-MKF-D40
COVER, INERTIAL MEASUREMENT UNIT
$22.03¢11 017
1
#006
64213-MJN-A01
CLIP, TWIST
$2.32¢1 162
1
#007
80102-MJS-J70
RUBBER, RR. FENDER
$1.86¢932
1
#008
83150-MKF-D80ZB
SHELTER SET, RR. (TYPE1) (WL)
$706.21¢353 107
1
#010
83154-MKF-D40
SHELTER, FR.
$30.07¢15 036
1
#011
83160-MKF-D80ZB
SHELTER SET, R. SIDE (TYPE1) (WL)
$239.99¢119 997
1
#012
83165-MKF-D40ZA
COVER, R. AIR CLEANER SIDE *NH1*(BLACK)
$20.49¢10 247
1
#013
83166-MKF-D40ZA
COVER, L. AIR CLEANER SIDE *NH1*(BLACK)
$20.49¢10 247
1
#014
83170-MKF-D80ZB
SHELTER SET, L. SIDE (TYPE1) (WL)
$250.78¢125 390
1
#015
86211-MJK-N20
BADGE, R. PRODUCT
$40.18¢20 091
1
#016
86212-MJK-N20
BADGE, L. PRODUCT
$40.18¢20 091
1
#017
90115-MFL-D20
SCREW, PAN (6X20)
$2.43¢1 213
1
#018
90502-KGB-610
COLLAR, HEAD SIDE COVER
$2.51¢1 254
1
#019
90852-446-630
PLUG, HOLE
$3.04¢1 518
1
