STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#1
28333-300-000
SPRING, KICK STARTER STOPPER
$3.65¢1 825
1
#001
28333-300-000
SPRING, KICK STARTER STOPPER
$3.65¢1 825
1
#002
50600-MJW-J00
HOLDER, R. MAIN STEP
$49.13¢24 563
1
#2
50600-MJW-J00
HOLDER, R. MAIN STEP
$49.13¢24 563
1
#3
50611-MJW-J00
COLLAR (12.7X11)
$1.16¢581
1
#003
50611-MJW-J00
COLLAR (12.7X11)
$1.16¢581
1
#004
50612-KYJ-305
ARM, R. STEP (COO)
$30.30¢15 150
1
#4
50612-KYJ-305
ARM, R. STEP (COO)
$30.30¢15 150
1
#5
50617-445-840
SPRING, R. STEP RETURN
$6.61¢3 306
1
#005
50617-445-840
SPRING, R. STEP RETURN
$6.61¢3 306
1
#006
50619-MM5-000
PLATE, STEP SETTING
$9.60¢4 800
1
#6
50619-MM5-000
PLATE, STEP SETTING
$9.60¢4 800
1
#7
50639-MFL-D20
PIN, STEP BAR
$3.65¢1 825
1
#007
50639-MFL-D20
PIN, STEP BAR
$3.65¢1 825
1
#8
50639-ML0-010
PIN, STEP BAR
$6.14¢3 069
1
#008
50639-ML0-010
PIN, STEP BAR
$6.14¢3 069
1
#9
50642-KYJ-305
ARM, L. STEP (COO)
$30.30¢15 150
1
#009
50642-KYJ-305
ARM, L. STEP (COO)
$30.30¢15 150
1
#10
50644-445-840
SPRING, L. STEP RETURN
$6.61¢3 306
1
#010
50644-445-840
SPRING, L. STEP RETURN
$6.61¢3 306
1
#11
50661-MJE-D00
RUBBER, MAIN STEP
$4.06¢2 031
1
#011
50661-MJE-D00
RUBBER, MAIN STEP
$4.06¢2 031
1
#12
50700-MJW-J00
HOLDER, L MAIN STEP
$35.84¢17 919
1
#012
50700-MJW-J00
HOLDER, L MAIN STEP
$35.84¢17 919
1
#13
50711-MGS-D30
ARM, Right PILLION STEP
$82.83¢41 413
1
#13
50711-MGS-305
ARM, Right PILLION STEP (COO)
$82.83¢41 413
1
#013
50711-MGS-D30
ARM, Right PILLION STEP
$82.83¢41 413
1
#013
50711-MGS-305
ARM, Right PILLION STEP (COO)
$82.83¢41 413
1
#14
50712-MGS-305
ARM, L. PILLION STEP (COO)
$70.94¢35 469
1
#014
50712-MGS-305
ARM, L. PILLION STEP (COO)
$70.94¢35 469
1
#14
50712-MGS-D30
ARM, L PILLION STEP
$70.94¢35 469
1
#014
50712-MGS-D30
ARM, L PILLION STEP
$70.94¢35 469
1
#015
50715-MJW-J00
HOLDER, R. PILLION STEP
$34.45¢17 225
1
#15
50715-MJW-J00
HOLDER, R. PILLION STEP
$34.45¢17 225
1
#16
50718-MN8-000
PLATE, PILLION STEP CLICK
$3.20¢1 600
1
#016
50718-MN8-000
PLATE, PILLION STEP CLICK
$3.20¢1 600
1
#17
50725-MJW-J00
HOLDER, L PILLION STEP
$33.46¢16 731
1
#017
50725-MJW-J00
HOLDER, L PILLION STEP
$33.46¢16 731
1
#018
90115-MV9-000
BOLT, MAIN STEP RUBBER SETTING
$4.45¢2 225
1
#18
90115-MV9-000
BOLT, MAIN STEP RUBBER SETTING
$4.45¢2 225
1
#019
90116-MGZ-J00
BOLT, SOCKET (8X22)
$1.23¢613
1
#19
90116-MGZ-J00
BOLT, SOCKET (8X22)
$1.23¢613
1
#20
92501-08020-0A
BOLT, CAP (8X20)
$3.65¢1 825
1
#020
92501-08020-0A
BOLT, CAP (8X20)
$3.65¢1 825
1
#021
94102-08000
WASHER, PLAIN (8MM)
$1.15¢575
1
#21
94102-08000
WASHER, PLAIN (8MM)
$1.15¢575
1
#22
94201-20150
PIN, SPLIT (2.0X15)
$1.34¢669
1
#022
94201-20150
PIN, SPLIT (2.0X15)
$1.34¢669
1
#23
96211-08000
BALL, STEEL (#8) (1/4)
$1.60¢800
1
#023
96211-08000
BALL, STEEL (#8) (1/4)
$1.60¢800
1
