STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#1
28333-300-000
SPRING, KICK STARTER STOPPER
$3.65¢1 825
1
#001
28333-300-000
SPRING, KICK STARTER STOPPER
$3.65¢1 825
1
#2
46525-KK0-003
DUST SEAL (17X20X2.5)
$6.13¢3 063
1
#002
46525-KK0-003
DUST SEAL (17X20X2.5)
$6.13¢3 063
1
#003
50603-033-010
PIN, STEP BAR JOINT
$3.89¢1 944
1
#3
50603-033-010
PIN, STEP BAR JOINT
$3.89¢1 944
1
#4
50603-MFJ-D00
PIN, STEP JOINT
$3.33¢1 663
1
#004
50603-MFJ-D00
PIN, STEP JOINT
$3.33¢1 663
1
#5
50607-MJP-G50
GUARD, Right HEEL
$15.10¢7 550
1
#005
50607-MJP-G50
GUARD, Right HEEL
$15.10¢7 550
1
#006
50615-MJP-G50ZA
BRACKET, R. STEP *NH105* (MAT BLACK)
$155.96¢77 981
1
#6
50615-MJP-G50ZA
BRACKET, R. STEP *NH105* (MAT BLACK)
$155.96¢77 981
1
#007
50616-MJP-305
STEP, R. (COO)
$40.06¢20 031
1
#7
50616-MJP-305
STEP, R. (COO)
$40.06¢20 031
1
#008
50617-KFB-840
SPRING, STEP RETURN
$8.66¢4 331
1
#8
50617-KFB-840
SPRING, STEP RETURN
$8.66¢4 331
1
#009
50625-MJP-G50ZA
BRACKET, L. STEP *NH105* (MAT BLACK)
$263.26¢131 631
1
#9
50625-MJP-G50ZA
BRACKET, L. STEP *NH105* (MAT BLACK)
$263.26¢131 631
1
#10
50642-MJP-305
STEP, Left (COO)
$38.89¢19 444
1
#010
50642-MJP-305
STEP, Left (COO)
$38.89¢19 444
1
#010
50642-MJP-G50
STEP, Left
$38.89¢19 444
1
#011
50661-MJP-G50
RUBBER, MAIN STEP
$11.38¢5 688
1
#11
50661-MJP-G50
RUBBER, MAIN STEP
$11.38¢5 688
1
#12
50662-MJP-G50
PLATE, STEP RUBBER SETTING
$8.94¢4 469
1
#012
50662-MJP-G50
PLATE, STEP RUBBER SETTING
$8.94¢4 469
1
#13
50707-MJP-G50
GUARD, L HEEL
$15.10¢7 550
1
#013
50707-MJP-G50
GUARD, L HEEL
$15.10¢7 550
1
#014
50715-MJP-G50ZA
HOLDER, R. PILLION STEP *NH105* (MAT BLACK)
$170.16¢85 081
1
#14
50715-MJP-G50ZA
HOLDER, R. PILLION STEP *NH105* (MAT BLACK)
$170.16¢85 081
1
#015
50716-MJP-G50
GUARD, PILLION HEEL
$20.49¢10 244
1
#15
50716-MJP-G50
GUARD, PILLION HEEL
$20.49¢10 244
1
#16
50718-KT7-761
PLATE, PILLION STEP CLICK
$4.86¢2 431
1
#016
50718-KT7-761
PLATE, PILLION STEP CLICK
$4.86¢2 431
1
#017
50720-K26-305
BAR, R. PILLION STEP (COO)
$52.59¢26 294
1
#17
50720-K26-305
BAR, R. PILLION STEP (COO)
$52.59¢26 294
1
#18
50725-MJP-G50ZA
HOLDER, L PILLION STEP NH105 (MAT BLACK)
$170.16¢85 081
1
#018
50725-MJP-G50ZA
HOLDER, L PILLION STEP NH105 (MAT BLACK)
$170.16¢85 081
1
#019
50730-K26-305
BAR, L. PILLION STEP (COO)
$52.59¢26 294
1
#19
50730-K26-305
BAR, L. PILLION STEP (COO)
$52.59¢26 294
1
#020
90112-KWT-900
BOLT, FLANGE (6X8)
$2.81¢1 406
1
#20
90112-KWT-900
BOLT, FLANGE (6X8)
$2.81¢1 406
1
#021
90114-MGE-D00
BOLT, SPECIAL (6X15)
$2.64¢1 319
1
#21
90114-MGE-D00
BOLT, SPECIAL (6X15)
$2.64¢1 319
1
#22
90118-MJN-A00
BOLT, SOCKET (10X28)
$5.34¢2 669
1
#022
90118-MJN-A00
BOLT, SOCKET (10X28)
$5.34¢2 669
1
#023
90118-MR1-000
SCREW, PAN (6X14)
$3.75¢1 875
1
#23
90118-MR1-000
SCREW, PAN (6X14)
$3.75¢1 875
1
#24
90155-MBL-610
BOLT, SOCKET (8X32)
$5.94¢2 969
1
#024
90155-MBL-610
BOLT, SOCKET (8X32)
$5.94¢2 969
1
#25
90526-GB0-930
WASHER (8.5X20)
$2.48¢1 238
1
#025
90526-GB0-930
WASHER (8.5X20)
$2.48¢1 238
1
#27
94101-06080
WASHER, PLAIN (6MM)
$0.84¢419
1
#027
94101-06800
WASHER, PLAIN (6MM)
$0.84¢419
1
#27
94101-06800
WASHER, PLAIN (6MM)
$0.84¢419
1
#027
94101-06080
WASHER, PLAIN (6MM)
$0.84¢419
1
#27
94101-06000
WASHER, PLAIN (6MM)
$0.84¢419
1
#027
94101-06000
WASHER, PLAIN (6MM)
$0.84¢419
1
#028
94102-08000
WASHER, PLAIN (8MM)
$1.15¢575
1
#28
94102-08000
WASHER, PLAIN (8MM)
$1.15¢575
1
#029
94201-16120
PIN, SPLIT (1.6X12)
$1.34¢669
1
#29
94201-16120
PIN, SPLIT (1.6X12)
$1.34¢669
1
#30
94201-20150
PIN, SPLIT (2.0X15)
$1.34¢669
1
#030
94201-20150
PIN, SPLIT (2.0X15)
$1.34¢669
1
#031
96211-08000
BALL, STEEL (#8) (1/4)
$1.60¢800
1
#31
96211-08000
BALL, STEEL (#8) (1/4)
$1.60¢800
1
