STEP

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de STEP

Repuestos

#1
28333-300-000
SPRING, KICK STARTER STOPPER
$3.36¢1 679
1
#2
50600-MJW-J00
HOLDER, R. MAIN STEP
$45.19¢22 597
1
#3
50611-MJW-J00
COLLAR (12.7X11)
$1.07¢535
1
#4
50612-KYJ-305
ARM, R. STEP (COO)
$27.88¢13 938
1
#5
50617-445-840
SPRING, R. STEP RETURN
$6.08¢3 042
1
#6
50619-MM5-000
PLATE, STEP SETTING
$8.83¢4 416
1
#7
50639-MFL-D20
PIN, STEP BAR
$3.36¢1 679
1
#8
50639-ML0-010
PIN, STEP BAR
$5.65¢2 823
1
#9
50642-KYJ-305
ARM, L. STEP (COO)
$27.88¢13 938
1
#10
50644-445-840
SPRING, L. STEP RETURN
$6.08¢3 042
1
#11
50661-MJE-D00
RUBBER, MAIN STEP
$3.74¢1 869
1
#12
50700-MJW-J00
HOLDER, L MAIN STEP
$32.97¢16 485
1
#13
50711-MGS-305
ARM, Right PILLION STEP (COO)
$76.20¢38 100
1
#13
50711-MGS-D30
ARM, Right PILLION STEP
$76.20¢38 100
1
#14
50712-MGS-305
ARM, L. PILLION STEP (COO)
$65.26¢32 631
1
#14
50712-MGS-D30
ARM, L PILLION STEP
$65.26¢32 631
1
#15
50715-MJW-J00
HOLDER, R. PILLION STEP
$31.69¢15 847
1
#16
50718-MN8-000
PLATE, PILLION STEP CLICK
$2.94¢1 472
1
#17
50725-MJW-J00
HOLDER, L PILLION STEP
$30.79¢15 393
1
#18
90115-MV9-000
BOLT, MAIN STEP RUBBER SETTING
$4.09¢2 047
1
#19
90116-MGZ-J00
BOLT, SOCKET (8X22)
$1.13¢564
1
#20
92501-08020-0A
BOLT, CAP (8X20)
$3.36¢1 679
1
#21
94102-08000
WASHER, PLAIN (8MM)
$1.06¢529
1
#22
94201-20150
PIN, SPLIT (2.0X15)
$1.23¢615
1
#23
96211-08000
BALL, STEEL (#8) (1/4)
$1.47¢736
1
