550F REAR WHEEL VL800TL9 E33
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
HUB, REAR
No Disponible
#2
RIM, REAR WHEEL (15M/CXMT4.00
$444.10¢222 048
#3
SPOKE SET, REAR WHEEL
$143.47¢71 737
#4
SPACER (17.5X25X113)
$30.59¢15 295
#5
.BUSH
$14.37¢7 187
#6
BEARING
$17.05¢8 527
#7
BEARING
$24.43¢12 213
#8
TUBE ASSY, WHEEL INNER
$70.41¢35 207
#9
PROTECTOR, WHEEL INNER TUBE
$9.17¢4 583
#10
PANEL, REAR BRAKE ANCHOR
$373.90¢186 950
#11
SHOE SET, BRAKE
$53.05¢26 525
#12
SPRING, SHOE
$5.06¢2 530
#13
CAM, BRAKE
$38.20¢19 101
#14
O RING (D:2.4,ID:14.8)
$2.12¢1 058
#15
WASHER (15.5X24X1.6)
$3.09¢1 547
#16
LEVER, BRAKE CAM
$58.02¢29 009
#17
BOLT
$3.66¢1 829
#18
JOINT, HUB DRIVEN
$338.88¢169 441
#19
O RING (D:2.1,ID:65)
$4.48¢2 242
#20
WASHER, THRUST
$3.36¢1 679
#21
BOLT (6X16)
$1.90¢949
#22
WASHER
$3.79¢1 897
#23
AXLE, REAR (L:302)
$104.73¢52 365
#24
SPRING
$11.15¢5 577
#25
NUT
$10.87¢5 434
#26
WASHER (17X30X3.2)
$2.96¢1 478
#27
SPACER, RH
$28.26¢14 128
#28
SPACER, LH
$28.66¢14 329
#29
TIRE, REAR (170/80-15M/C 77H) | GS-23R RW IRC
$331.37¢165 686
#31
ROD ASSY, REAR BRAKE
$31.53¢15 767
#32
.PIN (13X18)
$3.75¢1 874
#33
.WASHER
$2.69¢1 346
#34
COTTER PIN
$1.46¢730
#35
.SPRING
$2.39¢1 196
#36
.PIN (10X16)
$2.38¢1 190
#37
.NUT
$3.36¢1 679
#30-1
BALANCER, WHEEL | 15G
$9.60¢4 801
#30-2
BALANCER, WHEEL | 30G
$10.95¢5 474
