FUEL EVAPORATION RECYCLE SYSTEM

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de FUEL EVAPORATION RECYCLE SYSTEM

Repuestos

#1
30601-107010
CIRCLIP 5.6, A TYPE
$1.25¢627
1
#2
6090-360004
FUEL VAPOR HOSE 3
$28.74¢14 369
1
#3
8010-180018
JOINT,HEAT TRANSMIT PIPE
$1.25¢627
1
#4
30601-110010
CLAMP D10
$1.25¢627
1
#5
6090-360005
FUEL VAPOR HOSE 4
$9.19¢4 594
1
#6
30601-112010
CLAMP D12
$1.25¢627
1
#7
606B-360200
CANISTER
$57.49¢28 744
1
#8
6090-360002
FUEL VAPOR HOSE 2
$28.74¢14 369
1
#9
6090-360003
VACUUM PIPE, CANISTER
$5.74¢2 869
1
#10
30601-109010
CLAMP D9
$1.25¢627
1
#12
606B-360100
ANTI DUMP VALVE
$17.24¢8 619
1
#13
6090-360001
FUEL VAPOR HOSE 1
$9.19¢4 594
1
#14
8010-360001
VACUUM T JOINT
$2.29¢1 144
1
#15
801G-360200
VACUUM PIPE, CANISTER
$5.74¢2 869
1
#16
30102-060020840
INNER HEX SCREW M6X20
$1.14¢569
1
#17
609A-020200
SECOND GULP VALVE
$28.74¢14 369
1
#19
30601-114010
CLAMP D14
$1.25¢627
1
#20
30601-116010
CLAMP
$1.25¢627
1
#21
609A-020002
OUTLET PIPE, GULP VALVE
$28.74¢14 369
1
#22
609A-020001
INLET PIPE, GULP VALVE
$5.74¢2 869
1
#23
30601-117010
CLAMP D17
$2.29¢1 144
1
