PLASTICS 4

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de PLASTICS 4

Repuestos

#1
A010-040011-2000
BOTTOM PANEL,Right Hand
$68.99¢34 494
1
#2
A010-040010-2000
BOTTOM PANEL,Left Hand
$80.49¢40 244
1
#3
6KM-040702-8000
INNER HEX SCREW M6X12
$1.25¢627
1
#4
A000-041110
PLASTIC CLASP
No Disponible
1
#5
30110-421130010
SELF TAPPING SCREW ST4.2X13
$1.89¢943
1
#6
8010-000002
CLAMP ST4.2
$2.29¢1 144
1
#7
A010-040027-2000
SIDE GRILL,Left Hand
$5.74¢2 869
1
#8
A010-040023-2B30
SIDE PANEL,Left Hand
$103.49¢51 744
1
#9
6090-040302
RUBBER DAMPER
$1.25¢627
1
#10
9010-160102
WASHER, HEADLIGHT
$1.25¢627
1
#11
30006-060020870
BOLT M6x20
$2.29¢1 144
1
#12
A010-040125
COVER,Left Hand SIDE PANEL
$26.44¢13 219
1
#13
A010-040028-2000
SIDE GRILL,Right Hand
$5.74¢2 869
1
#14
A010-040024-2B30
SIDE PANEL,Right Hand
$103.49¢51 744
1
#15
A010-040126
COVER,Right Hand SIDE PANEL
$22.99¢11 494
1
#16
9DQV-160920-6001-M1
SIDE REFLECTOR (AMBER COLOR)
$5.74¢2 869
1
#17
30204-060810
NUT M6
$1.25¢627
1
#18
A010-044201-2000
WIND SHIELD,Right Hand
$11.49¢5 744
1
#19
A010-044101-2000
WIND SHIELD,Left Hand
$11.49¢5 744
1
#20
A000-060002
SCREW, CHAIN GUARD
$6.89¢3 444
1
#21
9060-040310
PLASTIC CLIPS
$1.25¢627
1
