MAB BRAKE ASSY BOSCH
⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Repuestos
#1
BOLT, FRONT BRAKE DISC
$1.36¢681
#2
FRONT RACK
$212.49¢106 244
#3
FRONT BRAKE DISC
$212.49¢106 244
#4
SCREW M6X16
$1.36¢681
#5
BRAKE HOSE
$87.49¢43 744
#6
WIRE CLIP, FRONT SPEED SENSOR
$4.99¢2 494
#8
SPRING
$7.49¢3 744
#9
SCREW M8X25
$2.49¢1 244
#10
REAR BRAKE DISC
No Disponible
#11
RING, REAR GEAR
No Disponible
#12
FIXED BOLT, BRAKE DISC
No Disponible
#13
MOUNTING PLATE,REAR CALIPER
No Disponible
#14
SPEED SENSOR, FRONT WHEEL
$87.49¢43 744
#15
MAB HYDRAULIC BRAKE ASSEMBLY
No Disponible
#16
REAR BRAKE CALIPER ASSEMBLY
No Disponible
#17
REAR BRAKE PAD ASSEMBLY
No Disponible
#18
WASHER
$1.36¢681
#19
BOLT
$4.99¢2 494
#20
REAR BRAKE FLUID INTAKE PIPE
No Disponible
#21
SCREW M6X16
$1.36¢681
#22
CLIP, BRAKE HOSE
$2.49¢1 244
#23
PIN SHAFT
$2.49¢1 244
#24
COTTER PIN. 2.0X16
$2.49¢1 244
#25
INNER HEX SCREW M6X20
$1.36¢681
#26
REAR BRAKE FLUID OUTLET HOSE
$74.99¢37 494
#27
HYDRAULIC SWITCH ASSEMBLY
$29.99¢14 994
#28
ABS CONTROLLER
No Disponible
#29
ABS BRACKET
$7.49¢3 744
#30
SCREW, RESERVOIR TANK COVER
$1.36¢681
#31
RESERVOIR TANK COVER
$8.74¢4 369
#32
BACKING PLATE, RESERVOIR TANK
$2.49¢1 244
#33
GASKET, RESERVOIR TANK
$2.49¢1 244
#34
RESERVOIR TANK
$31.24¢15 619
#35
HOSE CLIP 1
$2.49¢1 244
#36
RESERVOIR TANK HOSE
$7.49¢3 744
#37
FRONT BRAKE FLUID INLET HOSE
$124.99¢62 494
#38
FLUID OUTLET HOSE, FRONT BRAKE
$74.99¢37 494
#39
BRAKE LEVER
$49.99¢24 994
#40
CLAMP
$2.49¢1 244
#41
FLUID HOSE
$6.24¢3 119
#42
RESERVOIR TANK
$37.49¢18 744
#43
CAP, FLUID RESERVOIR
$11.24¢5 619
#44
FRONT BRAKE MASTER CYLINDER ASSEMBLY
$249.99¢124 994
#45
FRONT BRAKE PAD
$192.49¢96 244
#46
FRONT BRAKE CALIPER
$749.99¢374 994
#47
SCREW M10X60X1.25
$2.49¢1 244
#48
BOLT
$11.24¢5 619
#49
MASTER CYLINDER, REAR BRAKE
$112.49¢56 244
