FUEL TANK 3

⚠️ Verificar CantidadesRevisa el diagrama cuidadosamente. Si tu ensamble requiere múltiples unidades de un mismo número (ej: 6 tornillos idénticos), asegúrate de ajustar la cantidad de piezas manualmente antes de añadirlas al carrito.
Diagrama de FUEL TANK 3

Repuestos

#1
B5U-24129-00-P0
COVER, SIDE 1
$72.69¢36 346
1
#2
90183-05042-00
NUT, SPRING
$1.15¢575
1
#3
90480-01559-00
Grommet
$5.27¢2 633
1
#4
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#5
90464-04005-00
Clamp
$3.51¢1 754
1
#6
90520-04019-00
DAMPER, PLATE
$0.63¢316
1
#7
1RC-2413B-01-00
EMBLEM (replaces 1RC-2413B-00-00)
$21.98¢10 988
1
#8
B5U-2837N-00-00
GRILL, AIR INTAKE 1
$44.45¢22 224
1
#9
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#10
90480-01559-00
Grommet
$5.27¢2 633
1
#11
B5U-2838N-00-00
DUCT 1
$36.67¢18 337
1
#12
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#13
90183-05042-00
NUT, SPRING
$1.15¢575
1
#14
90269-06001-00
RIVET
$5.93¢2 967
1
#15
B5U-28345-00-00
MOLE 1
$43.72¢21 862
1
#16
90269-06001-00
RIVET
$5.93¢2 967
1
#17
90183-05042-00
NUT, SPRING
$1.15¢575
1
#18
B5U-2842M-00-00
COVER 1
$11.36¢5 681
1
#19
90269-06001-00
RIVET
$5.93¢2 967
1
#20
90183-05042-00
NUT, SPRING
$1.15¢575
1
#21
90387-06205-00
COLLAR
$5.76¢2 881
1
#22
90111-06175-00
BOLT,HEX. SOCKET BUTTON
$6.97¢3 484
1
#23
90109-06043-00
BOLT
$2.53¢1 265
1
#24
B5U-24139-00-P0
COVER, SIDE 2
$72.69¢36 346
1
#25
90183-05042-00
NUT, SPRING
$1.15¢575
1
#26
90480-01559-00
Grommet
$5.27¢2 633
1
#27
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#28
90464-04005-00
Clamp
$3.51¢1 754
1
#29
90520-04019-00
DAMPER, PLATE
$0.63¢316
1
#30
1RC-2413B-01-00
EMBLEM (replaces 1RC-2413B-00-00)
$21.98¢10 988
1
#31
B5U-2837R-00-00
GRILL, AIR INTAKE 2
$44.45¢22 224
1
#32
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#33
90480-01559-00
Grommet
$5.27¢2 633
1
#34
B5U-2838R-00-00
DUCT 2
$43.73¢21 867
1
#35
90167-05076-00
SCREW, TAPPING
$1.94¢972
1
#36
90183-05042-00
NUT, SPRING
$1.15¢575
1
#37
90269-06001-00
RIVET
$5.93¢2 967
1
#38
B5U-28346-00-00
MOLE 2
$43.72¢21 862
1
#39
90269-06001-00
RIVET
$5.93¢2 967
1
#40
90183-05042-00
NUT, SPRING
$1.15¢575
1
#41
B5U-2842N-00-00
COVER 2
$11.36¢5 681
1
#42
90269-06001-00
RIVET
$5.93¢2 967
1
#43
90183-05042-00
NUT, SPRING
$1.15¢575
1
#44
90387-06205-00
COLLAR
$5.76¢2 881
1
#45
90111-06175-00
BOLT,HEX. SOCKET BUTTON
$6.97¢3 484
1
#46
90109-06043-00
BOLT
$2.53¢1 265
1
#47
B5U-241B1-00-00
COVER, TANK
$20.32¢10 160
1
#48
90269-06001-00
RIVET
$5.93¢2 967
1
#49
90520-10039-00
DAMPER, PLATE
$1.36¢678
1
#50
29P-2816R-01-00
LABEL, WARNING GENERAL INFO.
$3.40¢1 702
1
